- S251-3O0
- 2nd Gen Intel® Xeon® Scalable Processors
- Intel® Xeon® W-3200 Processor Family
- Single processor, LGA 3647
- 6-Channel RDIMM/LRDIMM DDR4, 8 x DIMMs
- Supports Intel® Optane™ Persistent Memory
- Dual 1Gb/s LAN port (Intel® I210-AT)
- 1 x Dedicated management port
- 24 x 3.5" SATA/SAS hot-swappable bays
- 2 x 2.5" SATA hot-swappable bays on rear side
- Onboard 12Gb/s SAS expander
- 1 x M.2 slot with PCIe Gen3 x4 interface
- Up to 7 x LP PCIe Gen3 x16, x8, and x4 slots
- 1+1 1300W 80 PLUS Platinum redundant power supplies
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
SPECIFICATIONS
Dimensions (WxHxD, mm)
2U
438 x 87 x 880
438 x 87 x 880
Motherboard
MU71-SU0
CPU
2nd Generation Intel® Xeon® Scalable Processors
Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon® Silver Processor and Intel® Xeon® Bronze Processor
Intel® Xeon® W-3200 Processor Family
Single processor
Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon® Silver Processor and Intel® Xeon® Bronze Processor
Intel® Xeon® W-3200 Processor Family
Single processor
Socket
1 x LGA 3647
Socket P
Socket P
Chipset
Intel® C621 Chipset
Memory
8 x DIMM slots
DDR4 memory supported only
6-channel memory architecture
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
Supports Intel® Optane™ Persistent Memory (PMem)
1.2V modules: 2933/2666/2400/2133 MHz
DDR4 memory supported only
6-channel memory architecture
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
Supports Intel® Optane™ Persistent Memory (PMem)
1.2V modules: 2933/2666/2400/2133 MHz
LAN
Rear side:
2 x 1Gb/s LAN ports (Intel® I210-AT)
1 x 10/100/1000 management LAN
2 x 1Gb/s LAN ports (Intel® I210-AT)
1 x 10/100/1000 management LAN
Video
Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Storage
Side-accessed:
24 x 3.5" SATA/SAS hot-swappable bays
LSI SAS35x36R expander
SAS card is required to enable the 24 drive bays
Rear side:
2 x 2.5" SATA hot-swappable bays, NVMe supported with optional CNV3022 NVMe Card
Default configuration supports:
2 x SATA drives on rear side
Recommend optional 12Gb/s SAS cards:
CRA4448 (Hardware RAID Card)
CSA4648 (Software HBA Card)
24 x 3.5" SATA/SAS hot-swappable bays
LSI SAS35x36R expander
SAS card is required to enable the 24 drive bays
Rear side:
2 x 2.5" SATA hot-swappable bays, NVMe supported with optional CNV3022 NVMe Card
Default configuration supports:
2 x SATA drives on rear side
Recommend optional 12Gb/s SAS cards:
CRA4448 (Hardware RAID Card)
CSA4648 (Software HBA Card)
SAS
Supported via add-on SAS Card
RAID
Depends on RAID card
Expansion Slots
Total 7 x PCIe Gen3 low-profile slots
Slot_7: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU
Slot_6: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with Slot_7
Slot_5: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU
Slot_4: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with Slot_5
Slot_3: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU, reserved for optional NVMe Card
Slot_2: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with Slot_3, reserved for optional SAS Card
Slot_1: 1 x PCIe x4 (Gen3 x4) slot, from PCH
1 x M.2 slot:
- M-key
- PCIe Gen3 x4, from PCH
- Supports NGFF-2280 cards
Slot_7: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU
Slot_6: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with Slot_7
Slot_5: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU
Slot_4: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with Slot_5
Slot_3: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU, reserved for optional NVMe Card
Slot_2: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with Slot_3, reserved for optional SAS Card
Slot_1: 1 x PCIe x4 (Gen3 x4) slot, from PCH
1 x M.2 slot:
- M-key
- PCIe Gen3 x4, from PCH
- Supports NGFF-2280 cards
Internal I/O
1 x M.2 slot
1 x CPU fan header
6 x System fan headers
1 x USB 3.0 header
1 x TPM header
1 x VROC connector
1 x Front panel header
1 x Buzzer
1 x CPU fan header
6 x System fan headers
1 x USB 3.0 header
1 x TPM header
1 x VROC connector
1 x Front panel header
1 x Buzzer
Front I/O
2 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x System status LED
1 x HDD activity LED
2 x LAN activity LEDs
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x System status LED
1 x HDD activity LED
2 x LAN activity LEDs
Rear I/O
4 x USB 3.0
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED
Backplane Board
Left side: CBPD2C0: 12 x 3.5" SATA/SAS ports with expander
Right side: CBPD2C1: 12 x 3.5" SATA/SAS ports
Rear side: CBPD020: 2 x 2.5" NVMe/SATA hybrid ports
Right side: CBPD2C1: 12 x 3.5" SATA/SAS ports
Rear side: CBPD020: 2 x 2.5" NVMe/SATA hybrid ports
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Optional TPM2.0 kit: CTM010
Power Supply
1+1 1300W 80 PLUS Platinum redundant power supplies
AC Input:
- 100-240V~/ 12-7A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz
DC Input:
- 240Vdc/ 6.5A
DC Output:
- Max 1000W/ 100-240V~
+ 12V/ 80.5A
+ 12Vsb/ 3A
- Max 1300W/ 200-240V~ or 240Vdc Input
+ 12V/ 105.4A + 12Vsb/ 3A
AC Input:
- 100-240V~/ 12-7A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz
DC Input:
- 240Vdc/ 6.5A
DC Output:
- Max 1000W/ 100-240V~
+ 12V/ 80.5A
+ 12Vsb/ 3A
- Max 1300W/ 200-240V~ or 240Vdc Input
+ 12V/ 105.4A + 12Vsb/ 3A
System Management
Aspeed® AST2500 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
- Dashboard
- JAVA Based Serial Over LAN
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Windows Server 2012 R2 with Update
Windows Server 2016
Windows Server 2019
Red Hat Enterprise Linux 7.6 (x64) or later
Red Hat Enterprise Linux 8.0 (x64) or later
Red Hat Enterprise Linux 9.0 (x64) or later
SUSE Linux Enterprise Server 12 SP3 (x64) or later
SUSE Linux Enterprise Server 15 (x64) or later
Ubuntu 18.04 LTS (x64) or later
Ubuntu 20.04 LTS (x64) or later
Ubuntu 22.04 LTS (x64) or later
VMware ESXi 6.0 Update3 or later
VMware ESXi 6.5 Update2 or later
VMware ESXi 6.7 Update1 or later
VMware ESXi 7.0 or later
VMware ESXi 8.0 or later
Citrix Xenserver 7.1.0 CU2 or later
Citrix Xenserver 7.5.0 or later
Citrix Hypervisor 8.0.0 or later
Windows Server 2016
Windows Server 2019
Red Hat Enterprise Linux 7.6 (x64) or later
Red Hat Enterprise Linux 8.0 (x64) or later
Red Hat Enterprise Linux 9.0 (x64) or later
SUSE Linux Enterprise Server 12 SP3 (x64) or later
SUSE Linux Enterprise Server 15 (x64) or later
Ubuntu 18.04 LTS (x64) or later
Ubuntu 20.04 LTS (x64) or later
Ubuntu 22.04 LTS (x64) or later
VMware ESXi 6.0 Update3 or later
VMware ESXi 6.5 Update2 or later
VMware ESXi 6.7 Update1 or later
VMware ESXi 7.0 or later
VMware ESXi 8.0 or later
Citrix Xenserver 7.1.0 CU2 or later
Citrix Xenserver 7.5.0 or later
Citrix Hypervisor 8.0.0 or later
System Fans
6 x 60x60x38mm hot-swappable fan modules
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
1092 x 664 x 289 mm
Packaging Content
1 x S251-3O0
1 x CPU heatsink
1 x Rail kit
2 x Non-Fabric CPU carriers
1 x Cable arm
1 x CPU heatsink
1 x Rail kit
2 x Non-Fabric CPU carriers
1 x Cable arm
Part Numbers
- Barebone package: 6NS2513O0MR-00-1*
- Motherboard: 9MU71SU0MR-00
- Rail kit: 25HB2-A66124-C0R
- Cable arm: 25HBZ-R18100-K0R
- CPU heatsink: 25ST1-353105-T1R
- Fan module: 25ST2-663822-F1R
- Backplane board_12-port_L_Side: 9CBPD2C0NR-00
- Backplane board_12-port_R_Side: 9CBPD2C1NR-00
- Backplane board_2-port_rear_Side: 9CBPD020NR-00
- Power supply: 25EP0-213001-F3S
- 2-port NVMe card : 9CNV3022NR-00 (Optional)
- 12Gb/s SAS H/W RAID card : 9CRA4448NR-00 (Optional)
- 12Gb/s SAS S/W RAID card : 9CSA4648NR-00 (Optional)
- Motherboard: 9MU71SU0MR-00
- Rail kit: 25HB2-A66124-C0R
- Cable arm: 25HBZ-R18100-K0R
- CPU heatsink: 25ST1-353105-T1R
- Fan module: 25ST2-663822-F1R
- Backplane board_12-port_L_Side: 9CBPD2C0NR-00
- Backplane board_12-port_R_Side: 9CBPD2C1NR-00
- Backplane board_2-port_rear_Side: 9CBPD020NR-00
- Power supply: 25EP0-213001-F3S
- 2-port NVMe card : 9CNV3022NR-00 (Optional)
- 12Gb/s SAS H/W RAID card : 9CRA4448NR-00 (Optional)
- 12Gb/s SAS S/W RAID card : 9CSA4648NR-00 (Optional)
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
SUPPORT
Driver
BIOS
Utility
Firmware
QVL
- All
- All
- Windows Server 2019
- Windows Server 2016 64bit
- Windows Server 2012 R2 64bit
- Linux
Chipset
Chipset
Version
Size
Date
Intel® Chipset Driver
Version : 10.1.17861.8101
3.34 MB
Apr 18, 2019
OS: Windows Server 2012 R2 64bit,Windows Server 2016 64bit,Windows Server 2019
Intel® Chipset Driver
Version : 10.1.18228.8176
3.12 MB
Dec 29, 2019
OS: Windows Server 2012 R2 64bit,Windows Server 2016 64bit,Windows Server 2019
LAN
LAN
Version
Size
Date
Intel® LAN Driver and Utility
Version : 23.5
487.48 MB
Apr 18, 2019
OS: Windows Server 2012 R2 64bit,Linux,Windows Server 2016 64bit,Windows Server 2019
SATA RAID
SATA RAID
Version
Size
Date
Intel® SATA Preinstall driver
(For AHCI / RAID Mode)
Note: Windows setup to read from USB devices
(For AHCI / RAID Mode)
Note: Windows setup to read from USB devices
Version : 6.0.0.1357
6.54 MB
Apr 19, 2019
OS: Windows Server 2012 R2 64bit,Windows Server 2016 64bit,Windows Server 2019
Intel® Rapid Storage Technology enterprise (Intel® RSTe)
Version : 6.0.0.1357
265.09 MB
Apr 21, 2019
OS: Windows Server 2012 R2 64bit,Windows Server 2016 64bit,Windows Server 2019
Utility
BIOS
Warning:
Because BIOS flashing is potentially risky, if you do not encounter problems using the current version of BIOS, it is recommended that you not flash the BIOS. To flash the BIOS, do it with caution. Inadequate BIOS flashing may result in system malfunction.
What is a BETA?
BETA describes a new version that is reliable yet may not include all the features of the final product. During this phase we are previewing new features and gathering customer input to insure our product provides the best experience possible.
Because BIOS flashing is potentially risky, if you do not encounter problems using the current version of BIOS, it is recommended that you not flash the BIOS. To flash the BIOS, do it with caution. Inadequate BIOS flashing may result in system malfunction.
What is a BETA?
BETA describes a new version that is reliable yet may not include all the features of the final product. During this phase we are previewing new features and gathering customer input to insure our product provides the best experience possible.
- All
- All
- Windows Server 2022
- Windows Server 2019
- Windows Server 2016 R2 64bit
- Windows Server 2016 64bit
- Windows Server 2012 R2 64bit
- Windows Server 2012 64bit
- Windows 10 64bit
- VMware
- Ubuntu
- Linux CentOS
- Linux
Utility
Description
Version
Size
Date
GSM CLI
Version : 2.1.77
147.89 MB
Sep 27, 2024
OS: Windows Server 2012 64bit,Windows Server 2012 R2 64bit,Linux CentOS,Windows 10 64bit,Ubuntu,Windows Server 2016 R2 64bit,Windows Server 2019,Windows Server 2022
GSM Server
Version : 2.12
926.33 MB
Jan 18, 2023
OS: Linux,Windows Server 2016 64bit,Windows Server 2019
GSM Agent
Version : 2.5
720.29 MB
Dec 27, 2021
OS: Linux,Windows Server 2016 64bit,Windows Server 2019
Firmware
Description
Version
Size
Date
BMC Firmware with embedded GIGABYTE Management Console
(AST2500 AMI)
(AST2500 AMI)
Version : 12.61.21
105.38 MB
Apr 11, 2024
Anglais
Manual
Description
Version
Size
Date
Description
Version
Size
Date
RESOURCES
Success Case
Articles
Success Case | June 02, 2023
NCHC and Xanthus Elevate Taiwanese Animation on the World Stage with GIGABYTE Servers
Created by Greener Grass Production, the Taiwanese sci-fi mini-series “2049” made its debut on Netflix and various local TV channels. The animated spin-off “2049+ Voice of Rebirth”, crafted by Xanthus Animation Studio, premiered on the streaming service myVideo. The CGI show was created with the NCHC Render Farm’s GIGABYTE servers, which employ top-of-the-line NVIDIA® graphics cards to empower artists with industry-leading rendering capabilities. The servers can take on multiple workloads simultaneously through parallel computing, and they boast a wide range of patented smart features that ensure stability and availability. With all it has going for it, “2049+ Voice of Rebirth” may garner enough attention to become the breakout hit that will introduce Taiwanese animation to international audiences.
Success Case | April 23, 2023
Facial Recognition Brings AI Education to Taiwan's Schools
Taiwan's Ministry of Education is promoting AI learning. They want to reshape the school environment to make AI an integral part of students’ lives. In New Taipei, some elementary schools are installing GIGABYTE's AI-based facial recognition solution so students can check out books without a library card. Reading has never been easier, and educators can demonstrate the benefits of AI with this evergreen “teachable moment”.
Tech Guide | May 31, 2022
What is Private Cloud, and is it Right for You?
In the era of cloud computing, just about everyone has heard of the terms “private cloud” and “public cloud”. Chances are, you are using one or both of them in your everyday life—but how much do you really know about them? If you had the chance, could you build a private cloud for yourself or your organization? GIGABYTE Technology, an industry leader in server solutions used by global cloud service providers, is pleased to present our latest Tech Guide. We will examine the difference between private and public clouds, introduce the private cloud’s advantages and limitations, and then introduce GIGABYTE products that may help you build and operate a private cloud of your own.
Tech Guide | January 11, 2022
Cluster Computing: An Advanced Form of Distributed Computing
Cluster computing is a form of distributed computing that is similar to parallel or grid computing, but categorized in a class of its own because of its many advantages, such as high availability, load balancing, and HPC. GIGABYTE Technology, an industry leader in high-performance servers, presents this tech guide to help you learn about cluster computing. We also recommend GIGABYTE servers that can help you benefit from cluster computing.
Tech Guide | January 10, 2022
Setting the Record Straight: What is HPC? A Tech Guide by GIGABYTE
The term HPC, which stands for high performance computing, gets thrown around a lot nowadays, as server solutions become more and more ubiquitous. It is running the risk of becoming a catchall phrase: anything that is “HPC” must be the right choice for your computing needs. You may be wondering: what exactly are the benefits of HPC, and is HPC right for you? GIGABYTE Technology, an industry leader in high-performance servers, presents this tech guide to help you understand what HPC means on both a theoretical and a practical level. In doing so, we hope to help you evaluate if HPC is right for you, while demonstrating what GIGABYTE has to offer in the field of HPC.
Video
Video | July 28, 2021
Heroes Ascension
Over the past year or so, due to global warming and climate changes, all parts of the world have witnessed extreme weather events that are more severe than ...
News
Others
Back to S251-3O0
