Dimensions (WxHxD, mm)
1U
438 x 43.5 x 710
CPU
Intel® Xeon® 6300-Series Processors
Intel® Xeon® E-2400 Processors
Intel® Pentium® Gold G7400 / G7400T Processor
Single processor, TDP up to 95W
Memory
4 x DIMM slots
DDR5 memory supported
Dual Channel memory per processor
UDIMM: Up to 4400 MT/s (1DPC), 4000 MT/s (2DPC/1R), 3600 MT/s (2DPC/2R)
LAN
Rear:
2 x 1Gb/s LAN (2 x Intel® I210-AT)
- Support NCSI function
1 x 10/100/1000 Mbps Management LAN
Video
Integrated in ASPEED® AST2600
- 1 x Mini-DP
Storage
Front hot-swap:
2 x 3.5"/2.5" Gen4 NVMe/SATA [1]
2 x 3.5"/2.5" SATA
Internal M.2:
1 x M.2 (2280/22110), PCIe Gen4 x4, from CPU
[1] Hot-swap is not supported on NVMe drives.
RAID
Intel® SATA RAID 0/1/10/5
Support optional RAID add-in cards
PCIe Expansion Slots
Riser Card CRCE021:
- 1 x FHFL x16 (Gen5 x8), from CPU, occupied for NVMe
- 1 x FHFL x16 (Gen5 x8), from CPU, disabled
Riser Card CRSE016:
- 1 x FHHL x4 (Gen4 x4), from PCH
Front I/O
2 x USB 3.2 Gen1 ports (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED
Rear I/O
2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
2 x RJ45 ports
1 x MLAN port
1 x ID button with LED
Backplane Board
Speed and bandwidth:
PCIe Gen4 x4 or SATA 6Gb/s
Security Modules
1 x TPM header with SPI interface
-
Optional TPM2.0 kit:
CTM010
Power Supply
1+1 550W 80 PLUS Platinum redundant power supplies
AC Input:
- 100-240V~/ 8-4A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 2.75A
DC Output:
- Max 550W
+12V/ 44A
+12Vsb/ 2.1A
System Management
ASPEED
® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- Advanced Power Capping
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Please refer to OS compatibility table in support page
System Fans
2 x 40x40x56mm (29,700rpm)
2 x 40x40x56mm (32,000rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
982 x 594 x 250 mm
Packaging Content
1 x R133-X10-AAA2
1 x CPU heatsink
1 x Mini-DP to D-Sub cable
1 x 2-Section Rail kit
Part Numbers
- Barebone package (6300/E-2400): 6NR133X10MR000ABA2*
- Barebone package (E-2400): 6NR133X10MR000AAA2*
- Motherboard: 9MX14BL1NR-000*
- 2-Section Rail kit (CMA not supported): 25HB2-3A0203-K0R
- CPU heatsink: 25ST1-12311H-A7R
- M.2 heatsink: 12SP2-11000E-00R
- Front panel board - CFP1010: 9CFP1010NR-00*
- Backplane board - CBP1047: 9CBP1047NR-00*
- Fan module: 25ST2-405622-A0R
- Fan module: 25ST2-40562H-A0R
- Riser card - CRCE021: 9CRCE021NR-00*
- Riser card - CRSE016: 9CRSE016NR-00*
- NVMe card - CNV3080: 9CNV3080NR-00*
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- Power supply: 25EP0-205505-F3S
Optional parts:
- 3-Section Rail kit (Supports CMA): 25HB2-A56120-K0R
- Cable Management Arm: 25HBZ-R18100-K0R
* Das vorliegende Material dient nur zur Referenz. GIGABYTE behält sich das Recht vor, ohne Vorwarnung Inhalte zu verändern oder zu entfernen.
* Die beworbene Leistung basiert auf den maximal theoretischen Werten der Chipsatzhersteller oder von Organisationen, die die Interface-Spezifikationen erstellt haben. Die aktuelle Performance kann je nach Systemkonfiguration variieren.
* Alle Trademarks und Logos sind Eigentum der Markeninhaber.
* Aufgrund der Standard-PC-Architektur ist ein Teil des Speichers für die Nutzung des Systems reserviert und daher kann die aktuelle Speichergröße von der Speicherangabe abweichen.
