Insist on an Ultra Durable™ Motherboard for your new PC




Coming Soon
* Product features may vary by model.

Model Name
GA-Z77X-UP5 TH
GA-Z77X-UP4 TH
CPU Support
3rd and 2nd Gen Intel Core CPUs
3rd and 2nd Gen Intel Core CPUs
CPU Socket
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel Z77 chipset
Graphics Interface
1*PCIE 3.0X16+1*PCIE 3.0X8
1*PCIE 3.0X16+1*PCIE 3.0X8
Memory Type
Dual-Channel DDR3
2800/2600 (OC*)/1600 MHz
Dual-Channel DDR3
2800/2600 (OC*)/1600 MHz
Memory DIMM
4*DDR3(Max 32 GB)
4*DDR3 (Max 32 GB)
Expansion Slots
1*PCIEx4+3*PCIEx1+1*PCI
1*PCIEx4+3*PCIEx1+1*PCI
SAS/SATA connector
4*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
USB
10*USB3.0+6*USB2.0
8*USB3.0+6*USB2.0
Audio
8-channel HD
8-channel HD
1394
1*1394a
-
LAN
GbE LAN
GbE LAN
Video Output
HDMI/DVI/RGB/2xThunderblot port
HDMI/DVI/RGB/2xThunderblot port
Features & Software
Ultra Durable 5,
Thunderbolt support,
3D Power, 3D BIOS, WiFi+BlueTooth 4.0, Lucid MVP, mSATA, EZ Smart Response, SLI, CrossFireX, CFOS, On/off charge,
All Japanese Solid capacitors
Ultra Durable 5,
Thunderbolt support,
3D Power, 3D BIOS,
Lucid MVP, mSATA,
EZ Smart Response, SLI, CrossFireX, On/off charge,
All Japanese Solid capacitors
Form Factor (mm)
ATX(305x244)
ATX(305x244)



Model Name
GA-X79S-UP5 WIFI
GA-X79-UP4
CPU Support
2nd Generation Intel Core Processors
2nd Generation Intel Core Processors
CPU Socket
LGA 2011
LGA 2011
Chipset
Intel C606 chipset
Intel X79 chipset
Graphics Interface
2*PCIE 3.0X16+1*PCIE 3.0X8
2*PCIE 3.0X16+2*PCIE 3.0X8
Memory Type
4 Channel DDR3
2400/1866 (OC*)/1600 MHz
4 Channel DDR3
2400/1866 (OC*)/1600 MHz
Memory DIMM
8*DDR3(Max 64 GB)
8*DDR3(Max 64 GB)
Expansion Slots
1*PCIEx4+1*PCIEx1+1*PCI
2*PCIEx1+1*PCI
SAS/SATA connector
8*SAS+2*SATA 6Gb/s+6*SATA 3Gb/s
6*SATA 6Gb/s+6*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
USB
6*USB3.0+12*USB2.0
4*USB3.0+14*USB2.0
Audio
8-channel HD
8-channel HD
1394
2*1394a
-
LAN
Dual LAN
GbE LAN
Video Output
-
-
Features & Software
Ultra Durable 5,
3D Power, 3D BIOS,
3-Way SLI, 3-Way CrossFireX, On/Off Charge,
WIFI+BlueTooth 4.0, OC DualBIOS, eSATA, All Japanese Solid Capacitors, 110dB
Ultra Durable 5,
3D Power, 3D BIOS,
4-Way SLI, 4-Way CrossFireX,
On/Off Charge, All Japanese Solid Capacitors, 108dB
Form Factor (mm)
E-ATX(305x262)
ATX(305x244)
U : 2X Copper PCB     P : Power stage + All solid capacitor design
* Memory support is dependent on memory module compatibility and system OS.
* Motherboard models may vary based on local distribution.
* Please refer to GIGABYTE website for CPU support information.
