Insist on an Ultra Durable™ Motherboard for your new PC


|
Models
|





* Product features may vary by model.

Model Name
GA-Z77X-UP5 TH
GA-Z77X-UP5 TH
GA-Z77X-UP4 TH
GA-Z77X-UP4 TH
GA-Z77MX-D3H TH
GA-Z77MX-D3H TH
CPU Support
3rd and 2nd Gen Intel Core CPUs
3rd and 2nd Gen Intel Core CPUs
3rd and 2nd Gen Intel Core CPUs
CPU Socket
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel Z77 chipset
Intel Z77 chipset
Graphics Interface
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
Memory Type
Dual-Channel DDR3
2800/2600 (OC*)/1600MHz
Dual-Channel DDR3
2800/2600 (OC*)/1600MHz
Dual-Channel DDR3
2800 (OC*)/1600/1333 MHz
Memory DIMM
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Expansion Slots
1*PCIEx4+3*PCIEx1+1*PCI
1*PCIEx4+3*PCIEx1+1*PCI
2*PCIEx1
SATA connector
4*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
10* USB3.0+6*USB2.0
8* USB3.0+6*USB2.0
4* USB3.0+10*USB2.0
Video Output
HDMI/DVI/RGB/2xThunderbolt port
HDMI/DVI/RGB/2xThunderbolt port
HDMI/DVI/RGB/2xThunderbolt port
Audio
8-channel HD
8-channel HD
8-channel HD
1394
1*1394a
-
-
LAN
GbE LAN
GbE LAN
GbE LAN
Features & Software
Ultra Durable 5, Thunderbolt support, 3D Power, 3D BIOS,
WiFi+BlueTooth 4.0,
Lucid MVP, mSATA,
EZ Smart Response,
SLI, CrossFireX, On/off charge,
All Japanese Solid capacitors
Ultra Durable 5, Thunderbolt support, 3D Power, 3D BIOS, Lucid MVP,
mSATA, EZ Smart Response,
SLI, CrossFireX, On/off charge,
All Japanese Solid capacitors
Thunderbolt support, 3D Power,
3D BIOS, Ultra durable 4 Classic,
Lucid MVP, Dual UEFI BIOS,
SLI, CrossFireX,
On/off charge,
All Japanese Solid capacitors
Form Factor (mm)
ATX (305x244)
ATX (305x244)
mATX (244x244)



Model Name
G1. Sniper 3
G1. Sniper 3
GA-Z77X-UD5H
GA-Z77X-UD5H-WB WIFI
GA-Z77X-UD5H
GA-Z77X-UD3H
GA-Z77X-UD3H-WB WIFI
GA-Z77X-UD3H
CPU Support
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
CPU Socket
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel Z77 chipset
Intel Z77 chipset
Graphics Interface
2*PCIE 3.0 X16+ 2*PCIE 3.0 X8
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
Memory Type
Dual-Channel DDR3
2666(OC)/1600/1333 MHz
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
2666(OC)/1600/1333 MHz
Memory DIMM
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Expansion Slots
2*PCIEx1+ 1*PCI
1*PCIEx4+3*PCIEx1+ 1*PCI
1*PCIEx4+3*PCIEx1+ 1*PCI
SATA connector
6*SATA 6Gb/s+4*SATA 3Gb/s
6*SATA 6Gb/s+4*SATA 3Gb/s
4*SATA 6Gb/s+4*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
10* USB3.0+4*USB2.0
10* USB3.0+6*USB2.0
8* USB3.0+6*USB2.0
Video Output
HDMI,DVI,RGB,Display port
HDMI,DVI,RGB,Display port
HDMI,DVI,RGB,Display port
Audio
8-channel HD
8-channel HD
8-channel HD
1394
2*1394
2*1394
-
LAN
Dual LAN
Dual LAN
GbE LAN
Features & Software
3D Power, 3D BIOS,
Gen. 3 support, Ultra Durable 4,
EZ Smart Response,
Onboard OC buttons,
Creative Sound Core 3D, mSATA,
4 way SLI, 4 way CrossFireX, SLI,
On/off charge, Lucid MVP,
All Japanese Solid capacitors,
WiFi+Bluetooth 4.0, LAN Optimizer
3D Power, 3D BIOS,
Gen. 3 support, Ultra Durable 4,
EZ Smart Response,
Creative X-Fi MBII SW,
mSATA, CrossFireX, SLI,
On/off charge, LAN Optimizer,
All Japanese Solid capacitors,
Lucid MVP, WiFi+Bluetooth 4.0
3D Power, 3D BIOS,
Gen. 3 support, Ultra Durable 4,
EZ Smart Response,
mSATA, CrossFireX, SLI,
On/off charge, LAN Optimizer,
All Japanese Solid capacitors,
Lucid MVP, WiFi+Bluetooth 4.0
Form Factor (mm)
ATX (305x264)
ATX (305x244)
ATX (305x244)



Model Name
GA-Z77X-D3H
GA-Z77X-D3H
GA-Z77-D3H
GA-Z77-D3H
GA-Z77-DS3H
GA-Z77-DS3H
CPU Support
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
CPU Socket
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel Z77 chipset
Intel Z77 chipset
Graphics Interface
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4
Memory Type
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Memory DIMM
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Expansion Slots
1*PCIEx4+3*PCIEx1+ 1*PCI
3*PCIEx1+ 2*PCI
2*PCIEx1+ 2*PCI
SATA connector
4*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+3*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
8* USB3.0+6*USB2.0
6* USB3.0+10*USB2.0
4* USB3.0+8*USB2.0
Video Output
HDMI,DVI,RGB
HDMI,DVI,RGB
HDMI,DVI,RGB
Audio
8-channel HD
8-channel HD
8-channel HD
1394
-
-
-
LAN
GbE LAN
GbE LAN
GbE LAN
Features & Software
3D Power, 3D BIOS,
Gen. 3 support,
Ultra Durable 4 Classic, EZ Smart Response, mSATA,
CrossFireX, SLI, On/off charge,
All Japanese Solid capacitors,
LAN Optimizer, Lucid MVP
3D Power, 3D BIOS,
Gen. 3 support,
Ultra Durable 4 Classic
EZ Smart Response, mSATA,
CrossFireX, On/off charge,
All Japanese Solid capacitors,
LAN Optimizer, Lucid MVP
3D BIOS, Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response,
mSATA, CrossFireX,
On/off charge, Solid capacitors,
LAN Optimizer
Form Factor (mm)
ATX (305x225)
ATX (305x244)
ATX (305x215)



Model Name
GA-Z77P-D3
GA-Z77P-D3
G1.Sniper M3
G1.Sniper M3
GA-Z77MX-D3H
GA-Z77MX-D3H
CPU Support
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
CPU Socket
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel Z77 chipset
Intel Z77 chipset
Graphics Interface
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
Memory Type
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Memory DIMM
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Expansion Slots
2*PCIEx1+ 2*PCI
1*PCIEx4+ 1*PCIEx1
1*PCIEx4+ 1*PCIEx1
SATA connector
2*SATA 6Gb/s+3*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
4* USB3.0+8*USB2.0
4* USB3.0+8*USB2.0
4* USB3.0+10*USB2.0
Video Output
HDMI
HDMI,DVI,RGB,Display port
HDMI,DVI,RGB
Audio
8-channel HD
8-channel HD
8-channel HD
1394
-
-
-
LAN
GbE LAN
Intel GbE LAN
GbE LAN
Features & Software
3D BIOS, Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response,
mSATA, CrossFireX,
On/off charge, Solid capacitors,
LAN Optimizer
3D Power, 3D BIOS,
Gen. 3 support, Ultra Durable 4,
Creative Sound Core 3D,
EZ Smart Response, USB 3.0, SATA3, CrossFireX,
SLI, On/off charge,
All Japanese Solid capacitors,
Lucid MVP
3D Power, 3D BIOS,
Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response, CrossFireX,
SLI, On/off charge,
All Japanese Solid capacitors,
Lucid MVP, LAN Optimizer
Form Factor (mm)
ATX (305x215)
mATX (244x244)
mATX (244x244)



Model Name
GA-Z77M-D3H
GA-Z77M-D3H
GA-H77-D3H
GA-H77-D3H
GA-H77M-D3H
GA-H77M-D3H
CPU Support
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
CPU Socket
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel H77 chipset
Intel H77 chipset
Graphics Interface
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4
1*PCIE 3.0 x16 +1*PCIE 2.0 x4
1*PCIE 3.0 x16+1*PCIE 2.0 x4
Memory Type
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Memory DIMM
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Expansion Slots
1*PCIEx1+ 1*PCI
3*PCIEx1+ 2*PCI
1*PCIEx1+ 1*PCI
SATA connector
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
4* USB3.0+10*USB2.0
6* USB3.0+10*USB2.0
4* USB3.0+10*USB2.0
Video Output
HDMI,DVI,RGB
HDMI,DVI,RGB
HDMI,DVI,RGB
Audio
8-channel HD
8-channel HD
8-channel HD
1394
-
-
-
LAN
GbE LAN
GbE LAN
GbE LAN
Features & Software
3D BIOS, LAN Optimizer,
Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response,
CrossFireX, On/off charge,
All Japanese Solid capacitors
3D Power, 3D BIOS,
Gen. 3 support, LAN Optimizer,
Ultra Durable 4 Classic,
EZ Smart Response,USB 3.0,
SATA3, 3X power, mSATA,
CrossFireX, On/off charge,
All Japanese Solid capacitors
3D BIOS, Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response, USB 3.0,
SATA3, 3X power, CrossFireX,
On/off charge, LAN Optimizer,
All Japanese Solid capacitors
Form Factor (mm)
mATX (244x244)
ATX (305x244)
mATX(244x220)



Model Name
GA-Z77M-D3H-MVP
GA-Z77M-D3H-MVP
GA-H77-D3H-MVP
GA-H77-D3H-MVP
GA-H77-DS3H

GA-H77-DS3H
CPU Support
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
CPU Socket
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel H77 chipset
Intel H77 chipset
Graphics Interface
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4
1*PCIE 3.0 x16 +1*PCIE 2.0 x4
1*PCIE 3.0 x16+1*PCIE 2.0 x4
Memory Type
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Memory DIMM
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Expansion Slots
1*PCIEx1+ 1*PCI
3*PCIEx1+ 2*PCI
2*PCIEx1+ 2*PCI
SATA connector
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+3*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
4* USB3.0+10*USB2.0
6* USB3.0+10*USB2.0
4* USB3.0+8*USB2.0
Video Output
HDMI,DVI,RGB
HDMI,DVI,RGB
HDMI,DVI,RGB
Audio
8-channel HD
8-channel HD
8-channel HD
1394
-
-
-
LAN
GbE LAN
GbE LAN
GbE LAN
Features & Software
3D BIOS, LAN Optimizer,
Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response,
CrossFireX, On/off charge,
All Japanese Solid capacitors,
Lucid MVP
3D Power, 3D BIOS,
Gen. 3 support, LAN Optimizer,
Ultra Durable 4 Classic,
EZ Smart Response,USB 3.0,
SATA3, 3X power, mSATA,
CrossFireX, On/off charge,
All Japanese Solid capacitors,
Lucid MVP
3D BIOS, Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response, CrossFireX,
On/off charge, Solid capacitors,
LAN Optimizer
Form Factor (mm)
mATX (244x220)
ATX (305x244)
ATX (305x215)

U : 2 x copper PCB design     D : All solid capacitor design     P : Power stage + All solid capacitor design
* PCIe Gen. 3 is dependent on CPU and expansion card compatibility.
* Memory support is dependent on memory module compatibility and system OS.
* Product features may vary by model.
* Motherboard models may vary based on local distribution.
Please refer to GIGABYTE website for CPU support information.




Share the webpage to Facebook and Twitter :
All intellectual property rights, including without limitation to copyright and trademark of this work and its derivative works are the property of, or are licensed to,
GIGA-BYTE TECHNOLOGY CO., LTD. Any unauthorized use is strictly prohibited.
