Series Bo Mạch Chủ UD7

  GA-X58A-UD7
Intel® X58 + ICH10R Chipset

  1. Ultra Durable 3 Technology with copper cooled quality for lower working temperature
  2. Latest onboard NEC SuperSpeed USB 3.0 with superfast transfer rates of up to 5 Gbps
  3. 3X USB power delivery for greater compatibility and extra power for USB devices
  4. Latest Marvell SE9128 high speed SATA3 storage interface with superfast 6 Gbps link speed
  5. Supports the new Intel Core i7 processors with socket LGA1366 and feautring QPI 6.4 GT/s
  6. Revolution energy saving design with DES 2 featuring hardware based Dynamic 6-Gear switching
  7. Supports 3 channel DDR3 2100+ memory
  8. Scalable ability to both 3 way CrossFireX and 3 way SLI support for ultimate graphics performance
  9. Advanced 24 power phase design with VRD 11.1 support
  10. New Hybrid Silent-Pipe 2 design provides unequalled heat conductivity
  11. Unique hardware control IC to provide more precision voltage control
  12. 100% 50,000 hour lifespan Japanese solid capacitors design
  13. Onboard Debug LED display simplifies motherboard troubleshooting
  14. Patented GIGABYTE DualBIOS™ technology delivering highest level failure protection
  15. 2 Gigabit Ethernet LAN with Teaming functionality
  16. Supports Dolby Home Theater audio to create a stunning surround sound listening experience
  17. Power/reset/Clr CMOS onboard button for easily operation on the workbench
  18. Blu-ray playback outputs supported by high quality 108dB SNR ALC889 HD audio
  19. Compatible with Window 7 to deliver the best operation experience
  20. Meets European Union EuP(Energy-using Products) requirements

USB 3.0 Motherboards


  GA-P55A-UD7
Intel® P55 Chipset

  1. Industry leading 24phase power VRM design for optimum power efficiency and thermal solution
  2. Leading quality standard of Ultra Durable™ 3 technology with 2oz copper PCB design
  3. Latest onboard NEC SuperSpeed USB 3.0 with superfast transfer rates of up to 5 Gbps
  4. 3X USB power delivery for greater compatibility and extra power for USB devices
  5. Latest Marvell SE9128 high speed SATA3 storage interface with superfast 6Gbps link speed
  6. Support Intel Core i7/ Core i5/ Core i3 processors with LGA 1156 socket
  7. Dynamic Energy Saver™ 2 technology enables best energy efficiency
  8. Innovative Smart 6 technology for smarter PC management
  9. Supports dual channel DDR3 2600+ memory
  10. Scalable ability to both 3 way CrossFireX and 3 way SLI support for ultimate graphics performance
  11. Smart DualLAN with Intelligent LAN port auto-switching
  12. XHD technology accelerating hard drive performance with ease
  13. AutoGreen technology Greening your PC via Bluetooth cellphone.
  14. Patented GIGABYTE DualBIOS™ technology delivering highest level failure protection
  15. Supports Dolby Home Theater audio to create a stunning surround sound listening experience
  16. Hybrid Silent-Pipe design provides unequalled heat conductivity
  17. Onboard debug LED simplifies motherboard troubleshooting
  18. The Precision OV provides more precision voltage control for system
  19. Compatible with Windows 7 to deliver the best operation experience
  20. Meets European Union EuP(Energy-using Products) requirements

USB 3.0 Motherboards
