Models
|

Intel – P55A Series

  GA-P55A-UD6 GA-P55A-UD4P GA-P55A-UD3P GA-P55A-UD3


Model
GA-P55A-UD6
GA-P55A-UD6
GA-P55A-UD4P
GA-P55A-UD4P
GA-P55A-UD3P
GA-P55A-UD3P
GA-P55A-UD3
GA-P55A-UD3
CPU Support
Intel Core i7/ Core i5 Processors
Intel Core i7/ Core i5 Processors
Intel Core i7/ Core i5 Processors
Intel Core i7/ Core i5 Processors
CPU Socket
LGA1156
LGA1156
LGA1156
LGA1156
QPI/FSB
-
-
-
-
Chipset
Intel P55
Intel P55
Intel P55
Intel P55
Onboard Graphics
-
-
-
-
Graphics Interface
2*PCI-E 2.0 x16 slot
(x16 or 2x8)
2*PCI-E 2.0 x16 slot
(x16, x8)
1*PCI-E 2.0 x16+ 1*PCI-E x4
1*PCI-E 2.0 x16+ 1*PCI-E x4
Memory
Dual Channel DDR3 2600+/2200/1333/1066/800
Dual Channel DDR3 2200/1333/1066/800
Dual Channel DDR3 2200/1333/1066/800
Dual Channel DDR3 2200/1333/1066/800
Memory Socket
6*DDR3 (Max 16 GB)
4*DDR3 (Max 16 GB)
4*DDR3 (Max 16 GB)
4*DDR3 (Max 16 GB)
Expansion Slots
2*PCI + 2*PCI-Ex1

2*PCI + 3*PCI-Ex1

3*PCI +2*PCI-Ex1
3*PCI + 2*PCI-Ex1
ATA connector
2*SATA 6Gb/s
10*SATA 3Gb/s + 1*PATA
2*SATA 6Gb/s
8*SATA 3Gb/s + 1*PATA
2*SATA 6Gb/s
8*SATA 3Gb/s + 1*PATA
2*SATA 6Gb/s
6*SATA 3Gb/s + 1*PATA
RAID
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
Audio
HD Audio, 8-channel
HD Audio, 8-channel
HD Audio, 8-channel
HD Audio, 8-channel
IEEE 1394
3*IEEE 1394a
3*IEEE 1394a
-
-
USB 2.0
12*USB 2.0 2*USB 3.0
12*USB 2.0 2*USB 3.0
12*USB 2.0 2*USB 3.0
12*USB 2.0 2*USB 3.0
LAN
Dual Gigabit LAN
Dual Gigabit LAN
Gigabit LAN
Gigabit LAN
BIOS
Smart DualBIOS
Smart DualBIOS
Smart DualBIOS
Smart DualBIOS
Features
USB 3.0, SATA 6Gb/s, 3x USB power, 24 phase power, Ultra Durable 3, Dynamic Energy Saver 2, Smart TPM, ATI CrossFireX, SLI, Debug LED, Dolby Home Theater, Precision OV, eSATA/ USB combo
USB 3.0, SATA 6Gb/s, 3x USB power, Ultra Durable 3,
Dynamic Energy Saver 2, Smart TPM, ATI CrossFireX,
SLI, Dolby Home Theater,
Precision OV
USB 3.0, SATA 6Gb/s, 3x USB power, Ultra Durable 3,
Dynamic Energy Saver 2,
Smart TPM, ATI CrossFireX,
Dolby Home Theater, Precision OV
USB 3.0, SATA 6Gb/s, 3x USB power, Ultra Durable 3,
Dynamic Energy Saver 2,
ATI CrossFireX, Precision OV
Software
Smart 6, XHD, EasyTune 6
Smart 6, XHD, EasyTune 6
Smart 6, XHD, EasyTune 6
Smart 6, XHD, EasyTune 6
Form Factor (mm)
ATX (305x244)
ATX (305x244)
ATX (305x244)
ATX (305x244)






Norton™ Internet Security
Fast, comprehensive, and up-to-the-minute protection against online threats. It safeguards your computer, identity, and home network without slowing you down.
It sets a new standard for speed and makes online shopping, banking, and browsing safer and more convenient than ever.


  U : 2 oz copper PCB design D : All solid capacitor design
*Product features may vary by model. *Motherboard models may vary based on local distribution.
*Please refer to GIGABYTE website for CPU support information.
