Model name |
|
|
|
CPU Support |
4th Generation Intel® Core™ processors |
4th Generation Intel® Core™ processors |
4th Generation Intel® Core™ processors |
CPU Socket |
LGA1150 |
LGA1150 |
LGA1150 |
Chipset |
Intel B85 Chipset |
Intel B85 Chipset |
Intel B85 Chipset |
Graphics Interface |
1*PCIE 3.0 x16 |
1*PCIE 3.0 x16 |
1*PCIE 3.0 x16 |
Memory Type |
2 Channel DDR3 |
2 Channel DDR3 |
2 Channel DDR3 |
Memory DIMM |
4*DDR3 |
4*DDR3 |
2*DDR3 |
Expansion Slots |
1*PCIEx4+2*PCIEx1+2*PCI |
1*PCIEx4+1*PCIEx1+4*PCI |
2*PCIEx1+1*PCI |
SATA Connectors |
4*SATA3+2*SATA2 |
4*SATA3+2*SATA2 |
4*SATA3+2*SATA2 |
USB |
4*USB 3.0+8*USB 2.0 |
4*USB 3.0+8*USB 2.0 |
4*USB 3.0+8*USB 2.0 |
Audio |
8-channel HD |
8-channel HD |
8-channel HD |
LAN |
GbE LAN |
GbE LAN |
GbE LAN |
Video output |
HDMI,DVI,D-Sub |
HDMI |
HDMI,DVI,D-Sub |
Features & Software |
Ultra Durable 4 Plus,
CrossFire,
All solid capacitors,
On/off charge,
Intel SBA |
Ultra Durable 4 Plus,
CrossFire,
All solid capacitors,
On/off charge,
Intel SBA |
Ultra Durable 4 Plus,
All solid capacitors,
On/off charge,
Intel SBA |
Form Factor(mm) |
ATX(305x225) |
ATX(305x225) |
mATX(244x174) |
|
Model name |
|
|
|
CPU Support |
4th Generation Intel® Core™ processors |
|
|
CPU Socket |
LGA1150 |
|
|
Chipset |
Intel B85 Chipset |
|
|
Graphics Interface |
1*PCIE 3.0 x16 |
|
|
Memory Type |
2 Channel DDR3 |
|
|
Memory DIMM |
4*DDR3 |
|
|
Expansion Slots |
1*PCIEx4+2*PCI |
|
|
SATA Connectors |
4*SATA3+2*SATA2 |
|
|
USB |
4*USB 3.0+8*USB 2.0 |
|
|
Audio |
8-channel HD |
|
|
LAN |
GbE LAN |
|
|
Video output |
HDMI,DVI,D-Sub |
|
|
Features & Software |
Ultra Durable 4 Plus,
CrossFire,
All solid capacitors,
On/off charge,
Intel SBA |
|
|
Form Factor(mm) |
mATX(244x225) |
|
|
Memory support is dependent on memory module compatibility and system OS.
• Motherboard models may vary based on local distribution. Please refer to GIGABYTE website for CPU support information.
• For further product information, please visit our website: www.gigabyte.us
* The specifications and pictures are subject to change without notice.
* All trademarks and logos are the properties of their respective holders.
|
Model Name |
![](GA-P75-D3.png)
GA-P75-D3 *
|
![](GA-B75M-D3H.png)
GA-B75M-D3H
|
![](GA-B75M-D3V.png)
GA-B75M-D3V
|
CPU Support |
Intel 3rd and 2nd gen Core CPUs |
Intel 3rd and 2nd gen Core CPUs
|
Intel 3rd and 2nd gen Core CPUs |
CPU Socket |
LGA 1155 |
LGA 1155 |
LGA 1155 |
FSB/BCLK |
100 |
100 |
100 |
Chipset |
Intel B75 Express chipset |
Intel B75 Express chipset |
Intel B75 Express chipset |
Graphics Interface |
1*PCIe 3.0x16 + 1*PCIe 2.0x4 |
1*PCIe 3.0x16 + 1*PCIe 2.0x4 |
1*PCIe 3.0x16 |
Memory Type |
Dual-Channel DDR3
1600/1333 MHz |
Dual-Channel DDR3
1600/1333 MHz |
Dual-Channel DDR3
1600/1333 MHz |
Memory DIMM |
4*DDR3 (Max 32 GB) |
4*DDR3 (Max 32 GB) |
2*DDR3 (Max 32 GB) |
Expansion Slots |
1*PCIe x1+4*PCI |
2*PCI |
2*PCIe x1+1*PCI |
SATA connector |
1*SATA 6Gb/s+ 4*SATA 3Gb/s |
1*SATA 6Gb/s+ 5*SATA 3Gb/s |
1*SATA 6Gb/s+ 5*SATA 3Gb/s |
USB |
4 USB 3.0 ports, 8 USB 2.0 ports |
4 USB 3.0 ports, 8 USB 2.0 ports |
4 USB 3.0 ports, 8 USB 2.0 ports |
Audio/LAN |
ALC887-VD2 / Realtek 8111F-VL |
ALC887 / Realtek 8111F-VL |
ALC887 / Qualcomm Atheros 8151 |
Video Output |
N/A |
RGB, DVI, HDMI |
RGB, DVI |
Features& Software |
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
SATA 3, 3X USB Power,mSATA, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer |
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
SATA 3, 3X USB Power, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer, GSM |
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,
USB3.0, SATA 3,
3X USB
Power(For USB3.0 only),
CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer |
Form Factor (mm) |
ATX 305x215 |
mATX 244x220 |
mATX 244x174 |
Model Name |
![GA-B75M-D3P](GA-B75M-D3P.png)
GA-B75M-D3P
|
![GA-B75M-HD3](GA-B75M-HD3.png)
GA-B75M-HD3
|
|
CPU Support |
Intel 3rd and 2nd gen Core CPUs
|
Intel 3rd and 2nd gen Core CPUs |
|
CPU Socket |
LGA 1155 |
LGA 1155 |
|
FSB/BCLK |
100 |
100 |
|
Chipset |
Intel B75 Express chipset |
Intel B75 Express chipset |
|
Graphics Interface |
1*PCIe 3.0x16 + 1*PCIe 2.0x4 |
|
|
Memory Type |
Dual-Channel DDR3
1600/1333 MHz |
Dual-Channel DDR3
1600/1333 MHz |
|
Memory DIMM |
4*DDR3 (Max 32 GB) |
|
|
Expansion Slots |
1*PCIe x1+1*PCI |
|
|
SATA connector |
3*SATA 6Gb/s+ 5*SATA 3Gb/s |
1*SATA 6Gb/s+5*SATA 3Gb/s
|
|
USB |
4 USB 3.0 ports, 8 USB 2.0 ports |
|
|
Audio/LAN |
ALC887 / Realtek 8111DP-VL |
Realtek ALC887 / Realtek 8111F |
|
Video Output |
RGB, DVI, HDMI, DisplayPort |
|
|
Features& Software |
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,
USB3.0, SATA 3,
3X USB
Power(For USB3.0 only), CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer |
USB 3.0, SATA 3,
Ultra durable 4 Classic,
All Solid capacitors,
On/Off Charge,Dual UEFI BIOS, Win8
|
|
Form Factor (mm) |
mATX 244x244 |
|
|
GSM -- GIGABYTE Stable Models
Guarantee at least one year stable product supply |
*This Intel B75 chipset motherboard DOES NOT support Intel HD Graphics or Intel Wireless Display (even when combined with an Intel WiFi module).
A discrete VGA card is required for graphics output. |
|
*PCIE Gen. 3 is dependent on CPU and expansion card compatibility. |
|
|
