Model Name

GA-P75-D3*

GA-B75M-D3H

GA-B75M-D3V
CPU Support
Intel 3rd and 2nd gen Core CPUs
Intel 3rd and 2nd gen Core CPUs
Intel 3rd and 2nd gen Core CPUs
CPU Socket
LGA 1155
LGA 1155
LGA 1155
FSB/BCLK
100
100
100
Chipset
Intel B75 Express chipset
Intel B75 Express chipset
Intel B75 Express chipset
Graphics Interface
1*PCIe 3.0x16 + 1*PCIe 2.0x4
1*PCIe 3.0x16 + 1*PCIe 2.0x4
1*PCIe 3.0x16
Memory Type
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Memory DIMM
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
2*DDR3 (Max 32 GB)
Expansion Slots
1*PCIe x1+4*PCI
2*PCI
2*PCIe x1+1*PCI
SATA connector
1*SATA 6Gb/s+ 4*SATA 3Gb/s
1*SATA 6Gb/s+ 5*SATA 3Gb/s
1*SATA 6Gb/s+ 5*SATA 3Gb/s
USB
4 USB 3.0 ports, 8 USB 2.0 ports
4 USB 3.0 ports, 8 USB 2.0 ports
4 USB 3.0 ports, 8 USB 2.0 ports
Audio/LAN
ALC887-VD2/Realtek 8111F-VL
ALC887/Realtek 8111F-VL
ALC887/Qualcomm Atheros 8151
Video Output
N/A
RGB/DVI/HDMI
RGB/DVI
Features& Software
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
 SATA 3, 3X USB Power,mSATA, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
 SATA 3, 3X USB Power, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer, GSM
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,
USB3.0, SATA 3,
3X USB Power(For USB3.0 only),
CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
Form Factor (mm)
ATX 305x215
mATX 244x220
mATX 244x174


Model Name
GA-B75M-D3P
GA-B75M-D3P
GA-B75M-HD3
GA-B75M-HD3

CPU Support
Intel 3rd and 2nd gen Core CPUs
Intel 3rd and 2nd gen Core CPUs
CPU Socket
LGA 1155
LGA 1155
FSB/BCLK
100
100
Chipset
Intel B75 Express chipset
Intel B75 Express chipset
Graphics Interface
1*PCIe 3.0x16 + 1*PCIe 2.0x4
1*PCI-E 3.0x16
Memory Type
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Memory DIMM
4*DDR3 (Max 32 GB)
2*DDR3 (Max 16GB)
Expansion Slots
1*PCIe x1+1*PCI
2*PCI-Ex1+1*PCI
SATA connector
3*SATA 6Gb/s+ 5*SATA 3Gb/s
1*SATA 6Gb/s+5*SATA 3Gb/s
USB
4 USB 3.0 ports, 8 USB 2.0 ports
4*USB 3.0+8*USB 2.0
Audio/LAN
ALC887/Realtek 8111DP-VL
Realtek ALC887/Realtek 8111F
Video Output
RGB/DVI/HDMI/DisplayPort
HDMI/ DVI/ D-sub
Features& Software
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,
USB3.0, SATA 3,
3X USB Power(For USB3.0 only), CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
USB 3.0, SATA 3,
Ultra durable 4 Classic,
All Solid capacitors,
On/Off Charge,Dual UEFI BIOS, Win8
Form Factor (mm)
mATX 244x244
mATX 224x174


GSM -- GIGABYTE Stable Models
Guarantee at least one year stable product supply

*This Intel B75 chipset motherboard DOES NOT support Intel HD Graphics or Intel Wireless Display (even when combined with an Intel WiFi module).
 A discrete VGA card is required for graphics output.


*PCIE Gen. 3 is dependent on CPU and expansion card compatibility.
