Insist on an Ultra Durable™ Motherboard for your new PC
 Main    |   Overview   |   Intel® SBA   |   Unique Features   |   Models





Model name
CPU Support
4th Generation Intel® Core™ processors
4th Generation Intel® Core™ processors
4th Generation Intel® Core™ processors
CPU Socket
LGA1150
LGA1150
LGA1150
Chipset
Intel B85 Chipset
Intel B85 Chipset
Intel B85 Chipset
Graphics Interface
1*PCIE 3.0 x16
1*PCIE 3.0 x16
1*PCIE 3.0 x16
Memory Type
2 Channel DDR3
2 Channel DDR3
2 Channel DDR3
Memory DIMM
4*DDR3
4*DDR3
4*DDR3
Expansion Slots
1*PCIE 2.0 x4+2*PCIEx1+2*PCI
1*PCIEx4+2*PCIEx1+2*PCI
1*PCIEx4+1*PCIEx1+4*PCI
SATA Connectors
4*SATA3+2*SATA2
4*SATA3+2*SATA2
4*SATA3+2*SATA2
USB
4*USB 3.0+8*USB 2.0
4*USB 3.0+8*USB 2.0
4*USB 3.0+8*USB 2.0
Audio
8-channel HD
8-channel HD
8-channel HD
LAN
GbE LAN
GbE LAN
GbE LAN
Video output
HDMI
HDMI,DVI,D-Sub
HDMI
Features & Software

Ultra Durable 4 Plus, All solid capacitors, Nichicon High End Audio Capacitors, AMP-UP Audio, OP-AMP Upgrade Kit, CrossFire, On/off charge,
110dB, Intel SBA

Ultra Durable 4 Plus, CrossFire,
All solid capacitors,
On/off charge, Intel SBA
Ultra Durable 4 Plus, CrossFire,
All solid capacitors,
On/off charge, Intel SBA
Form Factor(mm)
ATX(305x225)
ATX(305x225)
ATX(305x225)


Model name
CPU Support
4th Generation Intel® Core™ processors
4th Generation Intel® Core™ processors
4th Generation Intel® Core™ processors
CPU Socket
LGA1150
LGA1150
LGA1150
Chipset
Intel B85 Chipset
Intel B85 Chipset
Intel B85 Chipset
Graphics Interface
1*PCIE 3.0 x16
1*PCIE 3.0 x16
1*PCIE 3.0 x16
Memory Type
2 Channel DDR3
2 Channel DDR3
2 Channel DDR3
Memory DIMM
2*DDR3
4*DDR3
4*DDR3
Expansion Slots
2*PCIEx1+1*PCI
1*PCIEx4+2*PCI
2*PCIEx1
SATA Connectors
4*SATA3+2*SATA2
4*SATA3+2*SATA2
4*SATA3+2*SATA2
USB
4*USB 3.0+8*USB 2.0
4*USB 3.0+8*USB 2.0
4*USB 3.0+8*USB 2.0
Audio
8-channel HD
8-channel HD
8-channel HD
LAN
GbE LAN
GbE LAN
GbE LAN
Video output
HDMI,DVI,D-Sub
HDMI,DVI,D-Sub
HDMI,DVI,D-Sub
Features & Software
Ultra Durable 4 Plus,
All solid capacitors,
On/off charge, Intel SBA
Ultra Durable 4 Plus, CrossFire,
All solid capacitors,
On/off charge, Intel SBA
Ultra Durable 4 Plus
All solid capacitors,
On/off charge, Intel SBA
Form Factor(mm)
mATX(244x174)
mATX(244x225)
mATX(226 x 193)


Model name

CPU Support
4th Generation Intel® Core™ processors
4th Generation Intel® Core™ processors
CPU Socket
LGA1150
LGA1150
Chipset
Intel B85 Chipset
Intel B85 Chipset
Graphics Interface
1*PCIE 3.0 x16
1*PCIE 3.0 x16
Memory Type
2 Channel DDR3
2 Channel DDR3
Memory DIMM
2*DDR3
2*DDR3
Expansion Slots
2*PCIEx1+1*PCI
2*PCIEx1
SATA Connectors
4*SATA3+2*SATA2
4*SATA3+2*SATA2
USB
4*USB 3.0+8*USB 2.0
4*USB 3.0+8*USB 2.0
Audio
8-channel HD
8-channel HD
LAN
GbE LAN
GbE LAN
Video output
DVI,D-Sub
DVI,D-Sub
Features & Software
Ultra Durable 4 Plus,
All solid capacitors,
On/off charge, Intel SBA
Ultra Durable 4 Plus,
All solid capacitors,
On/off charge
*This model doesn't support SBA.
Form Factor(mm)
mATX(244x174)
mATX(226x174)

Memory support is dependent on memory module compatibility and system OS.
• Motherboard models may vary based on local distribution. Please refer to GIGABYTE website for CPU support information.
• For further product information, please visit our website: www.gigabyte.com
* The specifications and pictures are subject to change without notice.
