Alegeţi o placă de bază Ultra Durable™ pentru noul vostru PC


|
Modele
|





* Caracteristicile produselor pot varia în funcție de model.

Model
GA-Z77X-UP5 TH
GA-Z77X-UP5 TH
GA-Z77X-UP4 TH
GA-Z77X-UP4 TH
GA-Z77MX-D3H TH
GA-Z77MX-D3H TH
Suport CPU
3rd and 2nd Gen Intel Core CPUs
3rd and 2nd Gen Intel Core CPUs
3rd and 2nd Gen Intel Core CPUs
Socket CPU
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel Z77 chipset
Intel Z77 chipset
Interfață grafică
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
Tip memorie
Dual-Channel DDR3
2800/2600 (OC*)/1600MHz
Dual-Channel DDR3
2800/2600 (OC*)/1600MHz
Dual-Channel DDR3
2800 (OC*)/1600/1333 MHz
Sloturi memorie
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Sloturi expansiune
1*PCIEx4+3*PCIEx1+1*PCI
1*PCIEx4+3*PCIEx1+1*PCI
2*PCIEx1
conector SATA
4*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
10* USB3.0+6*USB2.0
8* USB3.0+6*USB2.0
4* USB3.0+10*USB2.0
Ieșiri video
HDMI/DVI/RGB/2xThunderbolt port
HDMI/DVI/RGB/2xThunderbolt port
HDMI/DVI/RGB/2xThunderbolt port
Audio
8-channel HD
8-channel HD
8-channel HD
1394
1*1394a
-
-
LAN
GbE LAN
GbE LAN
GbE LAN
Caracteristici & Software
Ultra Durable 5, Thunderbolt support, 3D Power, 3D BIOS,
WiFi+BlueTooth 4.0,
Lucid MVP, mSATA,
EZ Smart Response,
SLI, CrossFireX, On/off charge,
All Japanese Solid capacitors
Ultra Durable 5, Thunderbolt support, 3D Power, 3D BIOS, Lucid MVP,
mSATA, EZ Smart Response,
SLI, CrossFireX, On/off charge,
All Japanese Solid capacitors
Thunderbolt support, 3D Power,
3D BIOS, Ultra durable 4 Classic,
Lucid MVP, Dual UEFI BIOS,
SLI, CrossFireX,
On/off charge,
All Japanese Solid capacitors
Form Factor (mm)
ATX (305x244)
ATX (305x244)
mATX (244x244)



Model
G1. Sniper 3
G1. Sniper 3
GA-Z77X-UD5H
GA-Z77X-UD5H-WB WIFI
GA-Z77X-UD5H
GA-Z77X-UD3H
GA-Z77X-UD3H-WB WIFI
GA-Z77X-UD3H
Suport CPU
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Socket CPU
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel Z77 chipset
Intel Z77 chipset
Interfață grafică
2*PCIE 3.0 X16+ 2*PCIE 3.0 X8
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
Tip memorie
Dual-Channel DDR3
2666(OC)/1600/1333 MHz
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
2666(OC)/1600/1333 MHz
Sloturi memorie
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Sloturi expansiune
2*PCIEx1+ 1*PCI
1*PCIEx4+3*PCIEx1+ 1*PCI
1*PCIEx4+3*PCIEx1+ 1*PCI
conector SATA
6*SATA 6Gb/s+4*SATA 3Gb/s
6*SATA 6Gb/s+4*SATA 3Gb/s
4*SATA 6Gb/s+4*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
10* USB3.0+4*USB2.0
10* USB3.0+6*USB2.0
8* USB3.0+6*USB2.0
Ieșiri video
HDMI,DVI,RGB,Display port
HDMI,DVI,RGB,Display port
HDMI,DVI,RGB,Display port
Audio
8-channel HD
8-channel HD
8-channel HD
1394
2*1394
2*1394
-
LAN
Smart Dual LAN
Smart Dual LAN
GbE LAN
Caracteristici & Software
3D Power, 3D BIOS,
Gen. 3 support, Ultra Durable 4,
EZ Smart Response,
Onboard OC buttons,
Creative Sound Core 3D, mSATA,
4 way SLI, 4 way CrossFireX, SLI,
On/off charge, Lucid MVP,
All Japanese Solid capacitors,
WiFi+Bluetooth 4.0, LAN Optimizer
3D Power, 3D BIOS,
Gen. 3 support, Ultra Durable 4,
EZ Smart Response,
Creative X-Fi MBII SW,
mSATA, CrossFireX, SLI,
On/off charge, LAN Optimizer,
All Japanese Solid capacitors,
Lucid MVP, WiFi+Bluetooth 4.0
3D Power, 3D BIOS,
Gen. 3 support, Ultra Durable 4,
EZ Smart Response,
mSATA, CrossFireX, SLI,
On/off charge, LAN Optimizer,
All Japanese Solid capacitors,
Lucid MVP, WiFi+Bluetooth 4.0
Form Factor (mm)
ATX (305x244)
ATX (305x244)
ATX (305x244)



Model
GA-Z77X-D3H
GA-Z77X-D3H
GA-Z77-D3H
GA-Z77-D3H
GA-Z77-DS3H
GA-Z77-DS3H
Suport CPU
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Socket CPU
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel Z77 chipset
Intel Z77 chipset
Interfață grafică
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4
Tip memorie
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Sloturi memorie
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Sloturi expansiune
1*PCIEx4+3*PCIEx1+ 1*PCI
3*PCIEx1+ 2*PCI
2*PCIEx1+ 2*PCI
conector SATA
4*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+3*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
8* USB3.0+6*USB2.0
6* USB3.0+10*USB2.0
4* USB3.0+8*USB2.0
Ieșiri video
HDMI,DVI,RGB
HDMI,DVI,RGB
HDMI,DVI,RGB
Audio
8-channel HD
8-channel HD
8-channel HD
1394
-
-
-
LAN
GbE LAN
GbE LAN
GbE LAN
Caracteristici & Software
3D Power, 3D BIOS,
Gen. 3 support,
Ultra Durable 4 Classic, EZ Smart Response, mSATA,
CrossFireX, SLI, On/off charge,
All Japanese Solid capacitors,
LAN Optimizer, Lucid MVP
3D Power, 3D BIOS,
Gen. 3 support,
Ultra Durable 4 Classic
EZ Smart Response, mSATA,
CrossFireX, On/off charge,
All Japanese Solid capacitors,
LAN Optimizer, Lucid MVP
3D BIOS, Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response,
mSATA, CrossFireX,
On/off charge, Solid capacitors,
LAN Optimizer
Form Factor (mm)
ATX (305x225)
ATX (305x244)
ATX (305x215)



Model
GA-Z77P-D3
GA-Z77P-D3
G1.Sniper M3
G1.Sniper M3
GA-Z77MX-D3H
GA-Z77MX-D3H
Suport CPU
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Socket CPU
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel Z77 chipset
Intel Z77 chipset
Interfață grafică
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8
Tip memorie
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Sloturi memorie
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Sloturi expansiune
2*PCIEx1+ 2*PCI
1*PCIEx4+ 1*PCIEx1
1*PCIEx4+ 1*PCIEx1
conector SATA
2*SATA 6Gb/s+3*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
4* USB3.0+8*USB2.0
4* USB3.0+8*USB2.0
4* USB3.0+10*USB2.0
Ieșiri video
HDMI
HDMI,DVI,RGB,Display port
HDMI,DVI,RGB
Audio
8-channel HD
8-channel HD
8-channel HD
1394
-
-
-
LAN
GbE LAN
Intel GbE LAN
GbE LAN
Caracteristici & Software
3D BIOS, Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response,
mSATA, CrossFireX,
On/off charge, Solid capacitors,
LAN Optimizer
3D Power, 3D BIOS,
Gen. 3 support, Ultra Durable 4,
Creative Sound Core 3D,
EZ Smart Response, USB 3.0, SATA3, CrossFireX,
SLI, On/off charge,
All Japanese Solid capacitors,
Lucid MVP
3D Power, 3D BIOS,
Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response, CrossFireX,
SLI, On/off charge,
All Japanese Solid capacitors,
Lucid MVP, LAN Optimizer
Form Factor (mm)
ATX (305x215)
mATX (244x244)
mATX (244x244)



Model
GA-Z77M-D3H
GA-Z77M-D3H
GA-H77-D3H
GA-H77-D3H
GA-H77M-D3H
GA-H77M-D3H
Suport CPU
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Socket CPU
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel H77 chipset
Intel H77 chipset
Interfață grafică
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4
1*PCIE 3.0 x16 +1*PCIE 2.0 x4
1*PCIE 3.0 x16+1*PCIE 2.0 x4
Tip memorie
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Sloturi memorie
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Sloturi expansiune
1*PCIEx1+ 1*PCI
3*PCIEx1+ 2*PCI
1*PCIEx1+ 1*PCI
conector SATA
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
4* USB3.0+10*USB2.0
6* USB3.0+10*USB2.0
4* USB3.0+10*USB2.0
Ieșiri video
HDMI,DVI,RGB
HDMI,DVI,RGB
HDMI,DVI,RGB
Audio
8-channel HD
8-channel HD
8-channel HD
1394
-
-
-
LAN
GbE LAN
GbE LAN
GbE LAN
Caracteristici & Software
3D BIOS, LAN Optimizer,
Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response,
CrossFireX, On/off charge,
All Japanese Solid capacitors
3D Power, 3D BIOS,
Gen. 3 support, LAN Optimizer,
Ultra Durable 4 Classic,
EZ Smart Response,USB 3.0,
SATA3, 3X power, mSATA,
CrossFireX, On/off charge,
All Japanese Solid capacitors
3D BIOS, Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response, USB 3.0,
SATA3, 3X power, CrossFireX,
On/off charge, LAN Optimizer,
All Japanese Solid capacitors
Form Factor (mm)
mATX (244x244)
ATX (305x244)
mATX(244x220)



Model
GA-Z77M-D3H-MVP
GA-Z77M-D3H-MVP
GA-H77-D3H-MVP
GA-H77-D3H-MVP
GA-H77-DS3H

GA-H77-DS3H
Suport CPU
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Intel 22nm and 2nd Gen Core CPUs
Socket CPU
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel H77 chipset
Intel H77 chipset
Interfață grafică
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4
1*PCIE 3.0 x16 +1*PCIE 2.0 x4
1*PCIE 3.0 x16+1*PCIE 2.0 x4
Tip memorie
Dual-Channel DDR3
2400(OC)/1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Sloturi memorie
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Sloturi expansiune
1*PCIEx1+ 1*PCI
3*PCIEx1+ 2*PCI
2*PCIEx1+ 2*PCI
conector SATA
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+3*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
4* USB3.0+10*USB2.0
6* USB3.0+10*USB2.0
4* USB3.0+8*USB2.0
Ieșiri video
HDMI,DVI,RGB
HDMI,DVI,RGB
HDMI,DVI,RGB
Audio
8-channel HD
8-channel HD
8-channel HD
1394
-
-
-
LAN
GbE LAN
GbE LAN
GbE LAN
Caracteristici & Software
3D BIOS, LAN Optimizer,
Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response,
CrossFireX, On/off charge,
All Japanese Solid capacitors,
Lucid MVP
3D Power, 3D BIOS,
Gen. 3 support, LAN Optimizer,
Ultra Durable 4 Classic,
EZ Smart Response,USB 3.0,
SATA3, 3X power, mSATA,
CrossFireX, On/off charge,
All Japanese Solid capacitors,
Lucid MVP
3D BIOS, Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response, CrossFireX,
On/off charge, Solid capacitors,
LAN Optimizer
Form Factor (mm)
mATX (244x220)
ATX (305x244)
ATX (305x215)

U : design cu PCB cu 2x cupru     D : Design cu condensatori solizi     P : Design cu Power stage + condensatori solizi
* PCIe Gen. 3 este dependent de compatibilitatea CPU şi a cardurilor de expansiune.
* Memoriile suportate depind de compatibilitatea modulelor de memorie și sistemul de operare.
* Caracteristicile produsului pot varia în funcţie de model.
* Modelele de plăci de bază pot varia în funcţie de distribuţia locală.
Vizitați site-ul GIGABYTE pentru informaţii despre suportul CPU.




Răspândeşte pagina prin Facebook şi Twitter:
Toate drepturile de autor, inclusiv drepturile de copiere şi drepturile de marcă din acest site şi al lucrărilor derivate din acest site, sunt proprietatea, şi sunt
licențiate către, GIGA-BYTE Technology Co. LTD. Orice uz neautorizat este strict interzis.
