Model Name
GA-B75-D3V
GA-B75-D3V
GA-B75M-D3H
GA-B75M-D3H
GA-B75M-D3V
GA-B75M-D3V
CPU Support
Intel 3rd and 2nd gen Core CPUs
Intel 3rd and 2nd gen Core CPUs
Intel 3rd and 2nd gen Core CPUs
CPU Socket
LGA 1155
LGA 1155
LGA 1155
FSB/BCLK
100
100
100
Chipset
Intel B75 Express chipset
Intel B75 Express chipset
Intel B75 Express chipset
Graphics Interface
1*PCIe 3.0x16 + 1*PCIe 2.0x4
1*PCIe 3.0x16 + 1*PCIe 2.0x4
1*PCIe 3.0x16
Memory Type
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Memory DIMM
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
2*DDR3 (Max 32 GB)
Expansion Slots
3*PCIe x1+2*PCI
2*PCI
2*PCIe x1+1*PCI
SATA connector
1*SATA 6Gb/s+ 4*SATA 3Gb/s
1*SATA 6Gb/s+ 5*SATA 3Gb/s
1*SATA 6Gb/s+ 5*SATA 3Gb/s
USB
4 USB 3.0 ports, 8 USB 2.0 ports
4 USB 3.0 ports, 8 USB 2.0 ports
4 USB 3.0 ports, 8 USB 2.0 ports
Audio/LAN
ALC887-VD2/
Qualcomm Atheros 8151
ALC887/Realtek 8111F-VL
ALC887/Qualcomm Atheros 8151
Video Output
RGB/DVI
RGB/DVI/HDMI
RGB/DVI
Features& Software

Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
 SATA 3, 3X USB Power,mSATA, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
 SATA 3, 3X USB Power, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,
USB3.0, SATA 3,
3X USB Power(For USB3.0 only),
CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
Form Factor (mm)
ATX 305x215
mATX 244x220
mATX 244x174


Model Name
GA-P75-D3
GA-P75-D3*
GA-P75-D3P
GA-P75-D3P*
GA-B75M-D3P
GA-B75M-D3P
CPU Support
Intel 3rd and 2nd gen Core CPUs
Intel 3rd and 2nd gen Core CPUs
Intel 3rd and 2nd gen Core CPUs
CPU Socket
LGA 1155
LGA 1155
LGA 1155
FSB/BCLK
100
100
100
Chipset
Intel B75 Express chipset
Intel B75 Express chipset
Intel B75 Express chipset
Graphics Interface
1*PCIe 3.0x16 + 1*PCIe 2.0x4
1*PCIe 3.0x16 + 1*PCIe 2.0x4
1*PCIe 3.0x16 + 1*PCIe 2.0x4
Memory Type
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Memory DIMM
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
Expansion Slots
1*PCIe x1+4*PCI
1*PCIe x1+4*PCI
1*PCIe x1+1*PCI
SATA connector
1*SATA 6Gb/s+ 4*SATA 3Gb/s
1*SATA 6Gb/s+ 4*SATA 3Gb/s
3*SATA 6Gb/s+ 5*SATA 3Gb/s
USB
4 USB 3.0 ports, 8 USB 2.0 ports
4 USB 3.0 ports, 8 USB 2.0 ports
4 USB 3.0 ports, 8 USB 2.0 ports
Audio/LAN
ALC887-VD2/Realtek 8111F-VL
ALC887/Realtek 8111F-VL
ALC887/Realtek 8111DP-VL
Video Output
N/A
N/A
RGB/DVI/HDMI/DisplayPort
Features& Software
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
 SATA 3, 3X USB Power,mSATA, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
 SATA 3, 3X USB Power,mSATA, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,
USB3.0, SATA 3,
3X USB Power(For USB3.0 only), CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
Form Factor (mm)
ATX 305x215
ATX 305x217
mATX 244x244



Model Name
GA-B75M-HD3
GA-B75M-HD3
GA-B75M-D2V
GA-B75M-D2V

CPU Support
Intel 3rd and 2nd gen Core CPUs
Intel 3rd and 2nd gen Core CPUs

CPU Socket
LGA 1155
LGA 1155

FSB/BCLK
100
100

Chipset
Intel B75 Express chipset
Intel B75 Express chipset

Graphics Interface
1*PCI-E 3.0x16
1*PCI-E 3.0x16

Memory Type
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz

Memory DIMM
2*DDR3 (Max 16GB)
2*DDR3 (Max 16GB)

Expansion Slots
2*PCI-Ex1+1*PCI
2*PCI-Ex1

SATA connector
1*SATA 6Gb/s+5*SATA 3Gb/s
1*SATA 6Gb/s+5*SATA 3Gb/s

USB
4*USB 3.0+8*USB 2.0
4*USB 3.0+8*USB 2.0

Audio/LAN
Realtek ALC887/Realtek 8111F
Realtek ALC887/Realtek 8111F

Video Output
HDMI/ DVI/ D-sub
DVI/ D-sub

Features& Software
USB 3.0, SATA 3,
Ultra durable 4 Classic,
All Solid capacitors,
On/Off Charge,Dual UEFI BIOS, Win8
USB 3.0, SATA 3,
Ultra durable 4 Classic,
All Solid capacitors,
On/Off Charge, UEFI BIOS, Win8

Form Factor (mm)
mATX 224x174
mATX 226x174


*This Intel B75 chipset motherboard DOES NOT support Intel HD Graphics or Intel Wireless Display (even when combined with an Intel WiFi module).
 A discrete VGA card is required for graphics output.


*PCIE Gen. 3 is dependent on CPU and expansion card compatibility.
