Model name |
|
|
|
CPU Support |
4th Generation Intel® Core™ processors |
4th Generation Intel® Core™ processors |
4th Generation Intel® Core™ processors |
CPU Socket |
LGA1150 |
LGA1150 |
LGA1150 |
Chipset |
Intel B85 Chipset |
Intel B85 Chipset |
Intel B85 Chipset |
Graphics Interface |
1*PCIE 3.0 x16 |
1*PCIE 3.0 x16 |
1*PCIE 3.0 x16 |
Memory Type |
2 Channel DDR3 |
2 Channel DDR3 |
2 Channel DDR3 |
Memory DIMM |
4*DDR3 |
4*DDR3 |
4*DDR3 |
Expansion Slots |
1*PCIE 2.0 x4+2*PCIEx1+2*PCI |
1*PCIEx4+2*PCIEx1+2*PCI |
1*PCIEx4+1*PCIEx1+4*PCI |
SATA Connectors |
4*SATA3+2*SATA2 |
4*SATA3+2*SATA2 |
4*SATA3+2*SATA2 |
USB |
4*USB 3.0+8*USB 2.0 |
4*USB 3.0+8*USB 2.0 |
4*USB 3.0+8*USB 2.0 |
Audio |
8-channel HD |
8-channel HD |
8-channel HD |
LAN |
GbE LAN |
GbE LAN |
GbE LAN |
Video output |
HDMI |
HDMI,DVI,D-Sub |
HDMI |
Features & Software |
Ultra Durable 4 Plus,
All solid capacitors, Nichicon High End Audio Capacitors, AMP-UP Audio, OP-AMP Upgrade Kit, CrossFire,
On/off charge,
110dB, Intel SBA
|
Ultra Durable 4 Plus,
CrossFire,
All solid capacitors,
On/off charge,
Intel SBA |
Ultra Durable 4 Plus,
CrossFire,
All solid capacitors,
On/off charge,
Intel SBA |
Form Factor(mm) |
ATX(305x225) |
ATX(305x225) |
ATX(305x225) |
|
Model name |
|
|
|
CPU Support |
4th Generation Intel® Core™ processors |
4th Generation Intel® Core™ processors |
4th Generation Intel® Core™ processors |
CPU Socket |
LGA1150 |
LGA1150 |
LGA1150 |
Chipset |
Intel B85 Chipset |
Intel B85 Chipset |
Intel B85 Chipset |
Graphics Interface |
1*PCIE 3.0 x16 |
1*PCIE 3.0 x16 |
1*PCIE 3.0 x16 |
Memory Type |
2 Channel DDR3 |
2 Channel DDR3 |
2 Channel DDR3 |
Memory DIMM |
2*DDR3 |
4*DDR3 |
4*DDR3 |
Expansion Slots |
2*PCIEx1+1*PCI |
1*PCIEx4+2*PCI |
2*PCIEx1 |
SATA Connectors |
4*SATA3+2*SATA2 |
4*SATA3+2*SATA2 |
4*SATA3+2*SATA2 |
USB |
4*USB 3.0+8*USB 2.0 |
4*USB 3.0+8*USB 2.0 |
4*USB 3.0+8*USB 2.0 |
Audio |
8-channel HD |
8-channel HD |
8-channel HD |
LAN |
GbE LAN |
GbE LAN |
GbE LAN |
Video output |
HDMI,DVI,D-Sub |
HDMI,DVI,D-Sub |
HDMI,DVI,D-Sub |
Features & Software |
Ultra Durable 4 Plus,
All solid capacitors,
On/off charge,
Intel SBA |
Ultra Durable 4 Plus,
CrossFire,
All solid capacitors,
On/off charge,
Intel SBA |
Ultra Durable 4 Plus
All solid capacitors,
On/off charge,
Intel SBA |
Form Factor(mm) |
mATX(244x174) |
mATX(244x225) |
mATX(226 x 193) |
Model name |
|
|
|
CPU Support |
4th Generation Intel® Core™ processors |
4th Generation Intel® Core™ processors |
CPU Socket |
LGA1150 |
LGA1150 |
Chipset |
Intel B85 Chipset |
Intel B85 Chipset |
Graphics Interface |
1*PCIE 3.0 x16 |
1*PCIE 3.0 x16 |
Memory Type |
2 Channel DDR3 |
2 Channel DDR3 |
Memory DIMM |
2*DDR3 |
2*DDR3 |
Expansion Slots |
2*PCIEx1+1*PCI |
2*PCIEx1 |
SATA Connectors |
4*SATA3+2*SATA2 |
4*SATA3+2*SATA2 |
USB |
4*USB 3.0+8*USB 2.0 |
4*USB 3.0+8*USB 2.0 |
Audio |
8-channel HD |
8-channel HD |
LAN |
GbE LAN |
GbE LAN |
Video output |
DVI,D-Sub |
DVI,D-Sub |
Features & Software |
Ultra Durable 4 Plus,
All solid capacitors,
On/off charge,
Intel SBA |
Ultra Durable 4 Plus,
All solid capacitors,
On/off charge
*This model doesn't support SBA. |
Form Factor(mm) |
mATX(244x174) |
mATX(226x174) |
Memory support is dependent on memory module compatibility and system OS.
• Motherboard models may vary based on local distribution. Please refer to GIGABYTE website for CPU support information.
• For further product information, please visit our website: www.gigabyte.com
* The specifications and pictures are subject to change without notice.
* All trademarks and logos are the properties of their respective holders.
|
|
