Model Name
Z97X-UD5H-BK
Z97X-UD3H-BK
CPU support
4th & 5th Gen Intel® Core™ processors
4th & 5th Gen Intel® Core™ processors
4th & 5th Gen Intel® Core™ processors
CPU socket
LGA 1150
LGA 1150
LGA 1150
Chipset
Intel Z97 Chipset
Intel Z97 Chipset
Intel Z97 Chipset
Graphics Interface
2*PCI-E 3.0 x16+2*PCI-E 3.0 x8
1*PCI-E 3.0 x16+
1*PCI-E 3.0 x8+1*PCI-E x4
1*PCI-E 3.0 x16+
1*PCI-E 3.0 x8+1*PCI-E x4
Memory Type
2 Channel DDR3
2 Channel DDR3
2 Channel DDR3
Memory DIMM
4*DDR3
4*DDR3
4*DDR3
Expansion slots
3*PCI-Ex1
2*PCI-E x1+2 PCI
3*PCI-E x1+1*PCI
SATA connectors
10*SATA3, SATA EXPRESS
8 SATA3,M.2,SATA EXPRESS
6 SATA3,M.2,SATA EXPRESS
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
8*USB 3.0+8*USB 2.0
8*USB 3.0+6*USB 2.0
6*USB 3.0+8*USB 2.0
Audio
Creative Sound Core 3D
ALC1150 115dB HD audio
ALC1150 115dB HD audio
LAN
Dual GbE LAN(Killer+Intel)
Dual GbE LAN(Killer+Intel)
Intel GbE LAN
Video output
HDMI, DVI-I, DisplayPort
HDMI, DVI-D, D-SUB
HDMI, DVI-D, D-SUB
Features & Software
Black edition,Water block thermal design,4-way Graphics support, Digital CPU Power design,Durable Black Solid caps,High End Audio Caps,AMP-UP Audio,OP-AMP Upgradable, Gold Plated audio ports,Dual DAC-UP USB ports, Creative SBX PRO STUDIO, WIFI+Bluetooth 4.0
Black edition, 2-way SLI / 3-way CrossFire Graphics support, IR Digital CPU Power design, Durable Black Solid caps, 15µ Gold Plated CPU Socket, 2X Copper PCB, Dual BIOS with LED Indicators, Quick Buttons, OC-PEG, Debug Display, Audio Noise Guard
Black edition, 2-way SLI / 3-way CrossFire Graphics support, Durable Black Solid caps,
15µ Gold Plated CPU Socket, 2X Copper PCB, Dual BIOS, Audio Noise Guard, CFOS
Form Factor (mm)
ATX (305X244)
ATX (305X244)
ATX (305x225)






   G1™ Performance
   G1™ Audio
• Extreme Gaming 4-Way Graphics Support
• Precise Digital CPU Power Design
• SATA Express Support for up to 10 Gb/s Data Transfer
• Long Lifespan Durable Black Solid Caps
• GIGABYTE App Center Including EasyTune™ and Cloud Station™ Utilities
• Onboard OC Quick Buttons
• GIGABYTE AMP-UP Audio Technology
   - Creative Sound Core3D™ with Gold Plated Shielding
   - Swapable OP-AMP Technology with Gain Boost
   - Dedicated Audio Hardware Zone
   - Audio Noise Guard with Trace Path Lighting
   - Nichicon High-End Audio Capacitors
• Gold Plated Audio Ports
• Dual DAC-UP USB Ports

   G1™ Networking
   G1™ Looks
• Killer E2200 Gaming Networking Platform / Intel GbE LAN
• Bluetooth 4.0 + 867 Mbps 11AC Dual Band WIFI Card
• Locked and Loaded Extreme Water Block Thermal Design

Gaming Headphone Amplifier
Swapable OP-AMP Technology with Gain Boost

Audio Noise Guard
with Trace Path Lighting

High End Audio Capacitors

Quad Core Creative
Sound Core3D with Custom
Gold Plated Shielding

Killer E2200 Game Networking

4-Way Graphics Support
SLI™ / CrossFire™

GIGABYTE Patented DualBIOS™
with LED Indicators

Single BIOS Mode / DualBIOS™
DIP Switches

Bluetooth 4.0 + 867 Mbps
11AC Dual Band WIFI Card

Water Block Thermal Design
with G1/4 Threaded Fittings
Durable Black Solid Capacitors

8-pin CPU Power Connector

15µ Gold Plated LGA 1150 CPU Socket

IR Digital CPU Power Design


Dual Channel DDR3
Memory Slots


Quick Buttons
Onboard Power, Reset,
Clear CMOS Buttons,
Voltage Read Points



Debug Display

USB 3.0

OC-PEG Extra Power Connector for
Enhanced PCIe Stability


10 SATA 3 Connectors (Up to 6Gb/s)

SATA EXPRESS Connector (Up to 10Gb/s)
Front USB 3.0 Access
Control Panel

  7 Fan Connectors




DAC-UP
USB 2.0
Gold Plated
DVI-I
USB 3.0
Dual GbE LAN
(Intel® + Killer)

Gold Plated
Audio Jack

PS/2 port

Gold Plated
DisplayPort
Gold Plated
HDMI
USB 3.0

Optical Digital
Audio Output
OP-AMP
Audio Output
*4K display support is dependent on CPU
Hanya 8 konektor SATA3 yang tersedia ketika SATA EXPRESS diaktifkan.







   Performance
   Durable
• Precise Digital CPU Power Design
• SATA Express Support for up to 10 Gb/s Data Transfer
• M.2 Connector for SSDs Drives with up to 10 Gb/s Data Transfer
• Killer E2200 Gaming Networking Platform / Intel® GbE LAN
• Realtek ALC1150 115dB SNR HD Audio with Built-in Rear Audio Amplifier
• GIGABYTE App Center Including EasyTune™ and Cloud Station™ Utilities
• 2x Copper PCB Design (2 oz Copper PCB)
• Long Lifespan Durable Black™ Solid Caps
• Durable Gold Plated CPU Socket

  Safe
   Cool
• Patented DualBIOS™ (UEFI) Design
• ESD Protection for USB and LAN
• Power Failure Protection with Anti-Surge IC
• Humidity Protection with New Glass Fabric PCB
• All New Heat Sink Design
• Highly Efficient MOSFET Design


Durable Black™ Solid Capacitors

Audio Noise Guard

Killer E2200 Gaming Networking

115dB HD Audio

2-Way SLI™/ 3-Way CrossFire™
Multi-Graphics Support

M.2 Onboard Connector*
(Up to 10Gb/s)

GIGABYTE Patented DualBIOS™
with LED Indicators

OC-PEG Extra Power Connector for
Enhanced PCIe Stability

All New Heat Sink Design


8-pin CPU Power Connector


15µ Gold Plated LGA1150
CPU Socket


IR Digital CPU Power Design


Dual Channel
DDR3
Memory Slots


Quick Buttons
Onboard Power, Reset,
Clear CMOS Buttons,
Voltage Read Points


USB 3.0
Single BIOS Mode Switch
DualBIOS™ DIP Switches


Debug Display


8 SATA 3 Connectors (Up to 6Gb/s)


SATA EXPRESS Connector (Up to 10Gb/s)*


  6 Fan Connectors
SATA Express


*SATA Express connector & M.2 slot can only be enabled one at a time




USB 2.0
D-SUB
USB 3.0
Dual GbE LAN
(Intel® + Killer)

8-Ch HD Audio

PS/2 port

DVI-D
HDMI

USB 3.0
Optical Digital
Audio Output
*4K display support is dependent on CPU
Hanya 6 konektor SATA3 yang tersedia ketika SATA EXPRESS diaktifkan.







   Performance
   Durable
• SATA Express Support for up to 10 Gb/s Data Transfer
• M.2 Connector for SSDs Drives with up to 10 Gb/s Data Transfer
• Intel® GbE LAN with CFOS Internet Accelerator Software
• Realtek ALC1150 115dB SNR HD Audio with Built-in Rear Audio Amplifier
• GIGABYTE App Center Including EasyTune™ and Cloud Station™ Utilities
• 2x Copper PCB Design (2 oz Copper PCB)
• Long Lifespan Durable Black™ Solid Caps
• Durable Gold Plated CPU Socket

  Safe
   Cool
• Patented DualBIOS™ (UEFI) Design
• ESD Protection for USB and LAN
• Power Failure Protection with Anti-Surge IC
• Humidity Protection with New Glass Fabric PCB
• All New Heat Sink Design
• Highly Efficient MOSFET Design


Durable Black™ Solid Capacitors

Audio Noise Guard

2-Way SLI™/ 3-Way CrossFire™
Multi-Graphics Support

115 dB HD Audio

M.2 Onboard Connector*
(Up to 10Gb/s)

GIGABYTE Patented DualBIOS™
(UEFI) Design

SATA EXPRESS Connector*
(Up to 10Gb/s)

8-pin CPU Power Connector


15µ Gold Plated
LGA 1150 CPU Socket


All New Heat Sink Design


Dual Channel
DDR3
Memory Slots


6 SATA 3 Connectors
(Up to 6Gb/s)


Front USB 3.0


  5 Fan Connectors
SATA Express


*SATA Express connector & M.2 slot can only be enabled one at a time




Mouse Port
D-SUB
USB 3.0

Intel® GbE LAN
8-Ch HD Audio

Keyboard Port

DVI-D
HDMI
USB 2.0
USB 3.0
Optical Digital
Audio Output
*4K display support is dependent on CPU
Hanya 4 konektor SATA3 yang tersedia ketika SATA EXPRESS diaktifkan.




• Foto hanya sebagai referensi.Spesifikasi Motherboard dapat bervariasi tergantung model.
• Spesifikasi dan gambar dapat berubah tanpa pemberitahuan.
• Type Motherboard dapat bervariasi berdasarkan distribusi lokal.
• Dukungan Memory tergantung pada kompatibilitas memori modul dan sistem OS.
• Silakan lihat website GIGABYTE untuk informasi dukungan CPU.
