Insist on an Ultra Durable™ Motherboard for your new PC
Main  |  Overview  |  Intel® SBA  |  Unique Features  |  Models





Model Name
GA-B75-D3V
GA-B75-D3V

GA-B75M-D3H

GA-B75M-D3V
CPU Support
Intel 3rd and 2nd gen Core CPUs
Intel 3rd and 2nd gen Core CPUs
Intel 3rd and 2nd gen Core CPUs
CPU Socket
LGA 1155
LGA 1155
LGA 1155
FSB/BCLK
100
100
100
Chipset
Intel B75 Express chipset
Intel B75 Express chipset
Intel B75 Express chipset
Graphics Interface
1*PCIe 3.0x16 + 1*PCIe 2.0x4
1*PCIe 3.0x16 + 1*PCIe 2.0x4
1*PCIe 3.0x16
Memory Type
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Dual-Channel DDR3
1600/1333 MHz
Memory DIMM
4*DDR3 (Max 32 GB)
4*DDR3 (Max 32 GB)
2*DDR3 (Max 32 GB)
Expansion Slots
3*PCIe x1+2*PCI
2*PCI
2*PCIe x1+1*PCI
SATA connector
1*SATA 6Gb/s+ 4*SATA 3Gb/s
1*SATA 6Gb/s+ 5*SATA 3Gb/s
1*SATA 6Gb/s+ 5*SATA 3Gb/s
USB
4 USB 3.0 ports, 8 USB 2.0 ports
4 USB 3.0 ports, 8 USB 2.0 ports
4 USB 3.0 ports, 8 USB 2.0 ports
Audio/LAN
ALC887-VD2/
Qualcomm Atheros 8151
ALC887/Realtek 8111F-VL
ALC887/Qualcomm Atheros 8151
Video Output
RGB/DVI
RGB/DVI/HDMI
RGB/DVI
Features& Software

Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
 SATA 3, 3X USB Power,mSATA, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
 SATA 3, 3X USB Power, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,
USB3.0, SATA 3,
3X USB Power(For USB3.0 only),
CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
Form Factor (mm)
ATX 305x215
mATX 244x220
mATX 244x174




Model Name

GA-P75-D3*
CPU Support
Intel 3rd and 2nd gen Core CPUs
CPU Socket
LGA 1155
FSB/BCLK
100
Chipset
Intel B75 Express chipset
Graphics Interface
1*PCIe 3.0x16 + 1*PCIe 2.0x4
Memory Type
Dual-Channel DDR3
1600/1333 MHz
Memory DIMM
4*DDR3 (Max 32 GB)
Expansion Slots
1*PCIe x1+4*PCI
SATA connector
1*SATA 6Gb/s+ 4*SATA 3Gb/s
USB
4 USB 3.0 ports, 8 USB 2.0 ports
Audio/LAN
ALC887-VD2/Realtek 8111F-VL
Video Output
N/A
Features& Software
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
 SATA 3, 3X USB Power,mSATA, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
Form Factor (mm)
ATX 305x215

*This Intel B75 chipset motherboard DOES NOT support Intel HD Graphics or Intel Wireless Display (even when combined with an Intel WiFi module).
 A discrete VGA card is required for graphics output.


*PCIE Gen. 3 is dependent on CPU and expansion card compatibility.
