Modell |
|
|
|
|
CPU |
AMD AM3
PhenomII/ Athlon II CPU |
AMD AM3
PhenomII/ Athlon II CPU |
AMD AM3
PhenomII/ Athlon II CPU |
AMD AM3
PhenomII/ Athlon II CPU |
CPU Sockel |
AMD Sockel AM3 |
AMD Sockel AM3 |
AMD Sockel AM3 |
AMD Sockel AM3 |
FSB |
5200MT/s (HT3.0) |
5200MT/s (HT3.0) |
5200MT/s (HT3.0) |
5200MT/s (HT3.0) |
Chipsatz |
AMD 890FX + SB850 |
AMD 890FX + SB850 |
AMD 890GX + SB850 |
AMD 790X + SB850 |
Onboard Grafik |
- |
- |
ATI Radeon HD 4290 (DX10.1) |
- |
Grafikanschlüsse |
4*PCI-E 2.0 x16 slot (4*x8 or 1*x16+2*x8 or 2*x16) |
3*PCI-E 2.0 x16 slot (1*x16+2*x8 or 2*x16) |
2*PCI-E 2.0 x16 slot (x8, x8) |
2*PCI-E 2.0 x16 slot (x8, x8) |
Arbeitsspeicher |
Dual-Channel DDR3 1866+/1333/1066 |
Dual-Channel DDR3 1866+/1333/1066 |
Dual-Channel DDR3 1866+/1333/1066 |
Dual-Channel DDR3 1866+/1333/1066 |
Speicher DIMM |
4*DDR3 (Max 16GB) |
4*DDR3 (Max 16GB) |
4*DDR3 (Max 16GB) |
4*DDR3 (Max 16GB) |
Steckplätze |
2*PCI-E 2.0 x16 + 1*PCI |
1*PCI-E 2.0 x16 + 2*PCI-E 2.0 x1 + 1*PCI |
3*PCI-E 2.0 x1 + 2*PCI |
3*PCI-E 2.0 x1 + 2*PCI |
ATA-Anschlüsse |
6*SATA 6Gb/s + 2*eSATA/USB Combo + 2*SATA 3Gb/s +
1*PATA |
6*SATA 6Gb/s + 2*eSATA/USB Combo + 2*SATA 3Gb/s +
1*PATA |
6*SATA 6Gb/s +
2*SATA 3Gb/s + 1*PATA |
6*SATA 6Gb/s + 2*eSATA 3Gb/s + 2*SATA 3Gb/s + 1*PATA |
SATA RAID |
0, 1, 5, 10 (SB850)/ 0, 1, JBOD (JM363 & 362) |
0, 1, 5, 10 (SB850)/ 0, 1, JBOD (JM363 & 362) |
0, 1, 5, 10 (SB850)/ 0, 1, JBOD (JM363) |
0, 1, 5, 10 (SB850)/ 0, 1, JBOD (JM363 & 362) |
USB |
2* USB3.0 + 14*USB2.0 |
2* USB3.0 + 14*USB2.0 |
2* USB3.0 + 12*USB2.0 |
2* USB3.0 + 12*USB2.0 |
Audio |
8-channel HD |
8-channel HD |
8-channel HD |
8-channel HD |
1394 |
3*1394a |
3*1394a |
3*1394a |
3*1394a |
LAN |
2*GbE |
2*GbE |
1*GbE |
1*GbE |
Software |
USB 3.0, SATA 6Gb/s, 3x USB power, 8+2 phase, Ultra
Durable 3, Easy Energy Saver, Auto Unlock support,
On/Off Charge support, 4way ATI CrossFireX, Smart
DualLAN, Hybrid Silent-pipe2, Debug LED, Onboard Quick
Switches, EasyTune6, ErP Ready
|
USB 3.0, SATA 6Gb/s, 3x USB power, 8+2 phase, Ultra
Durable 3, Easy Energy Saver, Auto Unlock support,
On/Off Charge support, 3way ATI CrossFireX, Smart
DualLAN, Dolby Home Theater, Onboard Quick Switches,
Precision OV, EasyTune6, ErP Ready |
USB 3.0, SATA 6Gb/s, 3x USB power, 4+1 phase, Ultra
Durable 3 Classic, Easy Energy Saver, Auto Unlock
support, On/Off Charge support, ATI Hybrid
CrossFireX/CrossFireX, DDR3 SidePort memory, HDMI/DVI,
Dolby Home Theater, EasyTune6, ErP Ready |
USB 3.0, SATA 6Gb/s, 3x USB power, 8+2 phase, Ultra
Durable 3, Easy Energy Saver, Auto Unlock support,
On/Off Charge support,
ATI CrossFireX,
Dolby Home Theater, Precision OV, EasyTune6, ErP Ready |
Form Factor (mm) |
XL-ATX (325x244) |
ATX (305x244) |
ATX (305x244) |
ATX (305x244) |
|
Modell |
|
|
|
|
CPU |
AMD AM3
PhenomII/ Athlon II CPU |
AMD AM3
PhenomII/ Athlon II CPU |
AMD AM3
PhenomII/ Athlon II CPU |
AMD AM3
PhenomII/ Athlon II CPU |
CPU Sockel |
AMD Sockel AM3 |
AMD Sockel AM3 |
AMD Sockel AM3 |
AMD Sockel AM3 |
FSB |
5200MT/s (HT3.0) |
5200MT/s (HT3.0) |
5200MT/s (HT3.0) |
5200MT/s (HT3.0) |
Chipsatz |
AMD 870 + SB850 |
AMD 880G + SB850 |
AMD 880G + SB710 |
AMD 880G + SB850 |
Onboard Grafik |
- |
ATI Radeon HD 4250(DX10.1) |
ATI Radeon HD 4250(DX10.1) |
ATI Radeon HD 4250(DX10.1) |
Grafikanschlüsse |
1*PCI-E 2.0 x16 slot (x16) |
1*PCI-E 2.0 x16 slot (x16) |
1*PCI-E 2.0 x16 slot (x16) |
1*PCI-E 2.0 x16 slot (x16) |
Arbeitsspeicher |
Dual-channel DDR3 1866+/1333/1066 |
Dual-channel DDR3 1866+/1333/1066 |
Dual-channel DDR3 1866+/1333/1066 |
Dual-channel DDR3 1800+/1333/1066 |
Speicher DIMM |
4*DDR3 (Max 16GB) |
4*DDR3 (Max 16GB) |
4*DDR3 (Max 16GB) |
4*DDR3 (Max 16GB) |
Steckplätze |
1*PCI-E 2.0 x16 + 2*PCI-E 2.0 x1 + 3*PCI |
1*PCI-E 2.0 x16 + 2*PCI-E 2.0 x1 + 3*PCI |
1*PCI-E 2.0 x16 + 2*PCI-E 2.0 x1 + 3*PCI |
1*PCI-E 2.0 x16 + 1*PCI-E 2.0 x1 + 1*PCI |
ATA-Anschlüsse |
6*SATA 6Gb/s + 2*eSATA 3Gb/s +2*SATA 3Gb/s + 1*PATA |
6*SATA 6Gb/s +
2*SATA 3Gb/s + 1*PATA |
6*SATA 3Gb/s + 1*PATA |
5*SATA 6Gb/s + 1*eSATA 6Gb/s + 1*PATA |
SATA RAID |
0, 1, 5, 10 (SB850)/ 0, 1, JBOD (JM363 & 362) |
0, 1, 5, 10 (SB850)/ 0, 1, JBOD (JM363) |
0, 1, 10 (SB710) |
0, 1, 5, 10 (SB850) |
USB |
2* USB3.0 + 12*USB2.0 |
2* USB3.0 + 12*USB2.0 |
12*USB2.0 |
2* USB3.0 + 10*USB2.0 |
Audio |
8-channel HD |
8-channel HD |
8-channel HD |
8-channel HD |
1394 |
3*1394a |
3*1394a |
3*1394a |
2*1394a |
LAN |
1*GbE |
1*GbE |
1*GbE |
1*GbE |
Software |
USB 3.0, SATA 6Gb/s, 3x USB power, 8+2 phase, Ultra
Durable 3, Easy Energy Saver, Auto Unlock support,
On/Off Charge support,
Dolby Home Theater, Precision OV, EasyTune6, ErP Ready |
USB 3.0, SATA 6Gb/s, 3x USB power, 4+1 phase, Ultra
Durable 3 Classic, Easy Energy Saver, Auto Unlock
support, On/Off Charge support, Turbo 3D support, ATI
Hybrid CrossFireX, HDMI/DVI, Dolby Home Theater,
EasyTune6, ErP Ready |
4+1 phase, Ultra Durable 3 Classic, Easy Energy Saver,
ACC support, Turbo 3D support, ATI Hybrid CrossFireX,
HDMI/DVI, Dolby Home Theater, EasyTune6, ErP Ready |
USB 3.0, SATA 6Gb/s, 3x USB power, 4+1 phase, Ultra
Durable 3 Classic, Easy Energy Saver, Auto Unlock
support, On/Off Charge support, Turbo 3D support, ATI
Hybrid CrossFireX, HDMI/DVI, Dolby Home Theater,
EasyTune6, ErP Ready |
Form Factor (mm) |
ATX (305x230) |
ATX (305x244) |
ATX (305x229) |
mATX (244x244) |
|
Modell |
|
|
CPU |
AMD AM3
PhenomII/ Athlon II CPU |
AMD AM3
PhenomII/ Athlon II CPU |
CPU Sockel |
AMD Sockel AM3 |
AMD Sockel AM3 |
FSB |
5200MT/s (HT3.0) |
5200MT/s (HT3.0) |
Chipsatz |
AMD 880G + SB710 |
AMD 880G + SB710 |
Onboard Grafik |
ATI Radeon HD 4250(DX10.1) |
ATI Radeon HD 4250(DX10.1) |
Grafikanschlüsse |
1*PCI-E 2.0 x16 slot (x16) |
1*PCI-E 2.0 x16 slot (x16) |
Arbeitsspeicher |
Dual-channel DDR3 1800+/1333/1066 |
Dual-channel DDR3 1800+/1333/1066 |
Speicher DIMM |
4*DDR3 (Max 16GB) |
4*DDR3 (Max 16GB) |
Steckplätze |
1*PCI-E x1 + 2*PCI |
1*PCI-E x1 + 2*PCI |
ATA-Anschlüsse |
5*SATA 3Gb/s + 1*eSATA 3Gb/s + 1*PATA |
5*SATA 3Gb/s + 1*eSATA 3Gb/s + 1*PATA |
SATA RAID |
0, 1, 10 (SB710) |
0, 1, 10 (SB710) |
USB |
2* USB3.0 + 10*USB2.0 |
12*USB2.0 |
Audio |
8-channel HD |
8-channel HD |
1394 |
2*1394a |
2*1394a |
LAN |
1*GbE |
1*GbE |
Software |
USB 3.0, 3x USB power,
4+1 phase, Ultra Durable 3 Classic, Easy Energy
Saver, ACC support, Turbo 3D support, ATI Hybrid
CrossFireX, HDMI/DVI, Dolby Home Theater,
EasyTune6, ErP Ready |
4+1 phase, Ultra Durable 3 Classic, Easy Energy
Saver, ACC support, Turbo 3D support, ATI Hybrid
CrossFireX, HDMI/DVI, Dolby Home Theater,
EasyTune6, ErP Ready |
Form Factor (mm) |
mATX (244x244) |
mATX (244x244) |
|
|
U
: 2 oz Kupfer PCB Design D :
Komplett mit Polymerkondensatoren |
* Feature können je nach
Modell variieren
* Mainboards können aufgrund lokaler Besonderheiten
variieren.
* Weitere Informationen zu kompatiblen CPUs finden Sie auf
der GIGABYTE Webseite. |
|
* Spezifikationen und
Abbildungen können ohne Vorankündigungen geändert werden. |
* Alle Warenzeichen und
Logos sind Eigentum der Inhaber. |
|
|
