إصدار مرتقب |
|
* قد تختلف الخصائص باختلاف الموديل. |
|
الموديل |
|
|
|
|
المعالجات المدعومة |
3rd and 2nd Gen Intel Core CPUs
|
3rd and 2nd Gen Intel Core CPUs
|
3rd and 2nd Gen Intel Core
CPUs
|
|
مقبس المعالج |
LGA1155 |
LGA1155 |
LGA1155 |
|
الشريحة الرئيسية |
Intel Z77 chipset |
Intel Z77 chipset |
Intel Z77 chipset |
|
واجهة توصيل الجرافيك |
3*PCIE 3.0X16+2*PCIE 3.0X8
|
1*PCIE 3.0X16+1*PCIE 3.0X8
|
1*PCIE 3.0X16+1*PCIE 3.0X8
|
|
نوع الذاكرة |
Dual-Channel DDR3
2800/2600 (OC*)/1600
MHz
|
Dual-Channel DDR3
2800/2600 (OC*)/1600
MHz
|
Dual-Channel DDR3
2800/2600 (OC*)/1600
MHz
|
|
شقوق الذاكرة |
4*DDR3(Max 32 GB)
|
4*DDR3(Max 32 GB)
|
4*DDR3 (Max 32 GB) |
|
كروت التوسعة |
2*PCIEx1
|
1*PCIEx4+3*PCIEx1+1*PCI
|
1*PCIEx4+3*PCIEx1+1*PCI
|
|
واجهات توصيل SATA |
6*SATA 6Gb/s+4*SATA 3Gb/s
|
4*SATA 6Gb/s+4*SATA 3Gb/s
|
2*SATA 6Gb/s+4*SATA 3Gb/s
|
|
التوصيل الشبكي لأقراص التخزين |
RAID 0,1,5,10 |
RAID 0,1,5,10 |
RAID 0,1,5,10
|
|
USB |
10*USB3.0+4*USB2.0
|
10*USB3.0+6*USB2.0
|
8*USB3.0+6*USB2.0
|
|
الصوت |
8-channel HD |
8-channel HD |
8-channel HD
|
|
1394 |
- |
1*1394a
|
- |
|
الشبكة |
Dual LAN
|
GbE LAN
|
GbE LAN
|
|
خرج الفيديو |
HDMI/DVI/RGB/Display Port
|
HDMI/DVI/RGB/2xThunderbolt port
|
HDMI/DVI/RGB/2xThunderbolt
port
|
|
المميزات والبرامج |
Ultra Durable 5,
32 CPU VRM phase,
3D
Power, 3D BIOS,
WiFi+BlueTooth 4.0, Lucid MVP, mSATA, EZ
Smart Response,
4-Way SLI, 4-Way CrossFireX,
On/off
charge,
All Japanese Solid capacitors |
Ultra Durable 5,
Thunderbolt support,
3D Power, 3D BIOS, WiFi+BlueTooth 4.0, Lucid MVP, mSATA,
EZ Smart Response, SLI, CrossFireX, CFOS, On/off charge,
All Japanese Solid capacitors |
Ultra Durable 5,
Thunderbolt support,
3D Power, 3D BIOS,
Lucid MVP, mSATA,
EZ Smart
Response, SLI, CrossFireX, On/off charge,
All Japanese
Solid capacitors |
|
أبعاد اللوحة الرئيسية |
E-ATX(305x264)
|
ATX(305x244)
|
ATX(305x244)
| |
|
الموديل |
|
|
|
المعالجات المدعومة |
2nd Generation Intel Core
Processors
|
2nd Generation Intel Core
Processors
|
|
مقبس المعالج |
LGA 2011
|
LGA 2011
|
|
الشريحة الرئيسية |
Intel C606 chipset
|
Intel X79 chipset
|
|
واجهة توصيل الجرافيك |
2*PCIE 3.0X16+1*PCIE 3.0X8
|
2*PCIE 3.0X16+2*PCIE 3.0X8
|
|
نوع الذاكرة |
4 Channel DDR3
2400/1866 (OC*)/1600
MHz
|
4 Channel DDR3
2400/1866 (OC*)/1600
MHz
|
|
شقوق الذاكرة |
8*DDR3(Max 64 GB)
|
8*DDR3(Max 64 GB)
|
|
كروت التوسعة |
1*PCIEx4+1*PCIEx1+1*PCI
|
2*PCIEx1+1*PCI
|
|
واجهات توصيل SATA |
8*SAS+2*SATA 6Gb/s+4*SATA 3Gb/s
+2*eSATA
6Gb/s
|
6*SATA 6Gb/s+4*SATA 3Gb/s
+2*eSATA 6Gb/s
|
|
التوصيل الشبكي لأقراص التخزين |
RAID 0,1,5,10
|
RAID 0,1,5,10 |
|
USB |
6*USB3.0+12*USB2.0
|
4*USB3.0+14*USB2.0
|
|
الصوت |
8-channel HD |
8-channel HD |
|
1394 |
2*1394a
|
- |
|
الشبكة |
Dual LAN
|
GbE LAN
|
|
خرج الفيديو |
-
|
-
|
|
المميزات والبرامج |
Ultra Durable 5,
3D Power, 3D BIOS,
3-Way SLI, 3-Way CrossFireX, On/Off
Charge,
WIFI+BlueTooth 4.0, OC DualBIOS, eSATA, All
Japanese Solid Capacitors, 110dB |
Ultra Durable 5,
3D Power, 3D BIOS,
4-Way SLI, 4-Way CrossFireX,
On/Off Charge, All
Japanese Solid Capacitors |
|
أبعاد اللوحة الرئيسية |
E-ATX(305x262) |
ATX(305x244)
| |
U : 2X Copper PCB P : Power stage + All solid capacitor design
* Memory support is dependent on memory module compatibility and system OS.
* Motherboard models may vary based on local distribution.
* Please refer to GIGABYTE website for CPU support information. |
|
