GIGABYTE USB 3.0 Motherboards

Models

Intel – P55A Series

	GA-P55A-UD6	GA-P55A-UD5	GA-P55A-UD4	GA-P55A-UD3

Modell	GA-P55A-UD6	GA-P55A-UD5	GA-P55A-UD4	GA-P55A-UD3P
CPU Support	Intel Core i7/ Core i5 Processors	Intel Core i7/ Core i5 Processors	Intel Core i7/ Core i5 Processors	Intel Core i7/ Core i5 Processors
CPU Sockel	LGA1156	LGA1156	LGA1156	LGA1156
QPI/FSB	-	-	-	-
Chipsatz	Intel P55	Intel P55	Intel P55	Intel P55
Onboard Frafik	-	-	-	-
Grafik Schnittstelle	3*PCI-E 2.0 x16 slot (x16, x8, x4)	3*PCI-E 2.0 x16 slot (x16, x8, x4)	2*PCI-E 2.0 x16 slot (x16, x4)	1PCI-E 2.0 x1 1PCI-E x4
Speicher	Dual Channel DDR3 2600+/2200/1333/1066/800	Dual Channel DDR3 2600+/2200/1333/1066/800	Dual Channel DDR3 2200/1333/1066/800	Dual Channel DDR3 2200/1333/1066/800
Speicher Socket	6*DDR3 (Max 16 GB)	4*DDR3 (Max 16 GB)	4*DDR3 (Max 16 GB)	4*DDR3 (Max 16 GB)
Erweiterungs- Slots	2PCI + 2PCI-Ex1	2PCI + 2PCI-Ex1	3PCI + 2PCI-Ex1	3PCI +2PCI-Ex1
ATA Anschluss	2SATA 6Gb/s 10SATA 3Gb/s + 1*PATA	2SATA 6Gb/s 10SATA 3Gb/s + 1*PATA	2SATA 6Gb/s 6SATA 3Gb/s + 1*PATA	2SATA 6Gb/s 8SATA 3Gb/s + 1*PATA
RAID	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10
Audio	HD Audio, 8-channel	HD Audio, 8-channel	HD Audio, 8-channel	HD Audio, 8-channel
IEEE 1394	3*IEEE 1394a	3*IEEE 1394a	-	-
USB 2.0	12USB 2.0 2USB 3.0	12USB 2.0 2USB 3.0	12USB 2.0 2USB 3.0	12USB 2.0 2USB 3.0
LAN	Dual Gigabit LAN	Dual Gigabit LAN	Gigabit LAN	Gigabit LAN
BIOS	Smart DualBIOS	Smart DualBIOS	Smart DualBIOS	Smart DualBIOS
Merkmale	USB 3.0, SATA 6Gb/s, 3x USB power, 24 phase power, Ultra Durable 3, Dynamic Energy Saver 2, Smart TPM, ATI CrossFireX, SLI, Debug LED, Dolby Home Theater, Precision OV, eSATA/ USB combo	USB 3.0, SATA 6Gb/s, 3x USB power, 12 phase power, Ultra Durable 3, Dynamic Energy Saver 2, Smart TPM, ATI CrossFireX, SLI, Dolby Home Theater, Precision OV, eSATA/ USB combo	USB 3.0, SATA 6Gb/s, 3x USB power, Ultra Durable 3, Dynamic Energy Saver 2, ATI CrossFireX, Precision OV	USB 3.0, SATA 6Gb/s, 3x USB power, Ultra Durable 3, Dynamic Energy Saver 2, Smart TPM, ATI CrossFireX, Dolby Home Theater, Precision OV
Software	Smart 6, XHD, EasyTune 6	Smart 6, XHD, EasyTune 6	Smart 6, XHD, EasyTune 6	Smart 6, XHD, EasyTune 6
Form Faktor (mm)	ATX (305x244)	ATX (305x244)	ATX (305x244)	ATX (305x244)

Norton™ Internet Security
Fast, comprehensive, and up-to-the-minute protection against online threats. It safeguards your computer, identity, and home network without slowing you down.
It sets a new standard for speed and makes online shopping, banking, and browsing safer and more convenient than ever.

U : 2 oz copper PCB design D : All solid capacitor design
*Product features may vary by model. *Motherboard models may vary based on local distribution.
*Please refer to GIGABYTE website for CPU support information.
The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
