R163-ZG2-AAJ2

Rev. 3.x

Rack Server - AMD EPYC™ 9005/9004 - 1U UP 1 x PCIe Gen5 GPU

# AI # AI Inference # Visual Computing # Networking # Hybrid/Private Cloud Server

Supports 1 x Dual slot Gen5 GPU
Single AMD EPYC™ 9005/9004 Series Processors
12-Channel DDR5 RDIMM, 24 x DIMMs
Dual ROM Architecture
12 x 2.5" Gen5 NVMe/SATA/SAS-4 hot-swap bays
2 x M.2 slots with PCIe Gen3 x2 interface
1 x FHFL PCIe Gen5 x16 slot for GPUs
1 x FHFL PCIe Gen5 x16 slot
1 x FHHL PCIe Gen5 x16 slot
1 x OCP NIC 3.0 PCIe Gen5 x16 slot
Dual 2000W 80 PLUS Titanium redundant power supply

Ordering Numbers: 6NR163ZG2DR000ACJ2*

Quick Shipping See More Models More ready-to-ship models in the R163 series. R163-Z35-AAH1 R163-Z35-AAC1

Get a Quote

Compare

Get a Quote

* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

SPECIFICATIONS

Dimensions (WxHxD, mm)

1U
438 x 43.5 x 815

Motherboard

MZG3-GU0

CPU

AMD EPYC™ 9005 Series Processors
AMD EPYC™ 9004 Series Processors

Single processor, cTDP up to 400W^[1]
- At 25°C ambient, cTDP up to 500W

^[1]Please refer to the QVL on the support page or contact our sales representatives for verified CPU SKUs.

Socket

1 x LGA 6096
Socket SP5

Chipset

System on Chip

Memory

24 x DIMM slots
DDR5 memory supported
12-Channel memory per processor

AMD EPYC™ 9005:
RDIMM: Up to 5200 MT/s (1DPC)
RDIMM: Up to 4400 MT/s (1R 2DPC), 4000 MT/s (2R 2DPC)

AMD EPYC™ 9004:
RDIMM: Up to 4800 MT/s (1DPC), 3600 MT/s (2DPC)

LAN

Rear:
1 x 10/100/1000 Mbps Management LAN

Video

Integrated in ASPEED^® AST2600
- 1 x Mini-DP

Storage

Front hot-swap:
12 x 2.5" Gen5 NVMe/SATA/SAS-4^[1]

Internal M.2:
2 x M.2 (2280/22110), PCIe Gen3 x2

^[1]SAS card is required to support SAS drives.

SAS

Require SAS add-in cards

RAID

Require RAID add-in cards

PCIe Expansion Slots

PCIe Cable x 3:
- 1 x FHFL x16 (Gen5 x16), for GPUs
- 1 x FHFL x16 (Gen5 x16)^[1]
- 1 x FHHL x16 (Gen5 x16)

1 x OCP NIC 3.0 (Gen5 x16)
- Supports NCSI function

^[1]Blocked when a Dual slot GPU is installed.

Front I/O

1 x USB 3.2 Gen1 port (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x Reset button
2 x LAN activity LEDs (disabled)
1 x Storage activity LED
1 x System status LED

Rear I/O

2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
1 x MLAN port
1 x ID LED

Backplane Board

Speed and bandwidth:
PCIe Gen5 x4 or SATA 6Gb/s or SAS-4 24Gb/s

Security Modules

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM012

Power Supply

Dual 2000W 80 PLUS Titanium redundant power supply

AC Input:
- 100-120V~/ 12A, 50/60Hz
- 180-240V~/ 10A, 50/60Hz

DC Input: (Only for China)
- 240Vdc/ 10A

DC Output:
- Max 1000W/ 100-120V~
+12.2V/ 81.5A
+12Vsb/ 2.5A
- Max 1600W/ 180-199V~
+12.2V/ 131A
+12Vsb/ 2.5A
- Max 1800W/ 200-220V~
+12.2V/ 147.5A
+12Vsb/ 2.5A
- Max 2000W/ 221-240V~ or 240Vdc Input
+12.2V/ 163.5A
+12Vsb/ 2.5A

^[Note]GIGABYTE offers PSUs with various efficiency ratings and power outputs. Full redundancy may depend on your server configuration, and alternative PSU options may be needed. Please contact our sales representatives for the best power solution.

System Management

ASPEED^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Please refer to OS compatibility table in support page

System Fans

2 x 40x40x56mm (32,000rpm)
6 x 40x40x56mm (38,000rpm)

Operating Properties

Operating temperature: 10°C to 30°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Packaging Dimensions

1043 x 594 x 252 mm

Packaging Content

1 x R163-ZG2-AAJ2
1 x CPU heatsink
1 x Mini-DP to D-Sub cable
1 x GPU power cable (12VHPWR, 400mm)
1 x 2-Section Rail kit

Part Numbers

- Barebone package: 6NR163ZG2DR000ACJ2*
- Motherboard: 9MZG3GU0UR-000-3*
- 2-Section Rail kit (CMA not supported): 25HB2-3A0206-K0R
- CPU heatsink: 25ST1-553201-M1R
- M.2 heatsink: 12SP2-11000E-00R
- Front panel board - CFP1030: 9CFP1030NR-00*
- Backplane board - CBP10C2: 9CBP10C2NR-00*
- Fan module: 25ST2-40562H-A0R
- Fan module: 25ST2-40562O-D0R
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- GPU power cable (12VHPWR, 400mm): 25CRI-4000B0-Y4R
- Power supply: 25EP0-22000A-L0S

Optional parts:

- 3-Section Rail kit (Supports CMA): 25HB2-A56121-K0R
- Cable Management Arm: 25HB1-R18300-K0R
