    OS
    Windows 11 Pro (GIGABYTE recommends Windows 11 Pro for business.)
    Windows 11 Home
    UEFI Shell OS
    Windows 11 Pro (GIGABYTE recommends Windows 11 Pro for business.)
    Windows 11 Home
    UEFI Shell OS
    Windows 11 Pro (GIGABYTE recommends Windows 11 Pro for business.)
    Windows 11 Home
    UEFI Shell OS
    Windows 11 Pro (GIGABYTE recommends Windows 11 Pro for business.)
    Windows 11 Home
    UEFI Shell OS
    CPU
    Intel® Core™ i9-14900HX Processor (36M Cache, up to 5.8 GHz, 24 cores : 8 P-core and 16 E-core)

    Intel® Core™ i7-14650HX Processor (30M Cache, up to 5.2 GHz, 16 cores : 8 P-core and 8 E-core)
    Intel® Core™ i7-13650HX Processor (24M Cache, up to 4.9 GHz, 14 cores : 6 P-core and 8 E-core)
    Intel® Core™ i7-13650HX Processor (24M Cache, up to 4.9 GHz, 14 cores : 6 P-core and 8 E-core)
    Intel® Core™ i7-13650HX Processor (24M Cache, up to 4.9 GHz, 14 cores : 6 P-core and 8 E-core)
    Video Graphics
    NVIDIA® GeForce RTX™ 4070 Laptop GPU 8GB GDDR6

    Boost Clock 2175MHz / Maximum Graphics Power 140 W

    *May vary by scenario.

    NVIDIA® GeForce RTX™ 4060 Laptop GPU 8GB GDDR6

    Boost Clock 2370MHz / Maximum Graphics Power 140 W

    *May vary by scenario.

    NVIDIA® GeForce RTX™ 4060 Laptop GPU 8GB GDDR6

    Boost Clock 2370MHz / Maximum Graphics Power 105 W

    *May vary by scenario.

    NVIDIA® GeForce RTX™ 4050 Laptop GPU 6GB GDDR6

    Boost Clock 2370MHz / Maximum Graphics Power 105 W

    *May vary by scenario.

    Display
    16.0“ 16:10 WQXGA (2560x1600) 165Hz Display
    （100% sRGB, Pantone® Validated, TÜV Rheinland-certified, Dolby Vision®, NVIDIA® Advanced Optimus, G-SYNC）
    16.0“ 16:10 WQXGA (2560x1600) 165Hz Display
    （100% sRGB, Pantone® Validated, TÜV Rheinland-certified, Dolby Vision®, NVIDIA® Advanced Optimus, G-SYNC）
    16.0“ 16:10 WUXGA (1920x1200) 165Hz Display
    （45% NTSC, MUX Switch）
    16.0“ 16:10 WUXGA (1920x1200) 165Hz Display
    （45% NTSC, MUX Switch）
    System Memory
    2x DDR5 Slots (DDR5-5600MHz, Up to 64GB)

    * 2 x SO-DIMM sockets for expansion

    2x DDR5 Slots (DDR5-4800MHz, Up to 64GB)

    * 2 x SO-DIMM sockets for expansion

    2x DDR5 Slots (DDR5-4800MHz, Up to 64GB)

    * 2 x SO-DIMM sockets for expansion

    2x DDR5 Slots (DDR5-4800MHz, Up to 64GB)

    * 2 x SO-DIMM sockets for expansion

    Storage
    2x M.2 SSD slots (Supports 2x PCIe® Gen4x4 NVMe™ M.2 SSD, Up to 4TB)

    *The storage capacity may differ by country and region. Please contact your local dealers or retailers for the latest product information.
    **If there is any abnormality that cannot be attributed to Gigabyte/AORUS during the warranty period, it is not covered by the warranty. More info:https://member.aorus.com/global/productwarranty

    2x M.2 SSD slots (Supports 2x PCIe® Gen4x4 NVMe™ M.2 SSD, Up to 4TB)

    *The storage capacity may differ by country and region. Please contact your local dealers or retailers for the latest product information.
    **If there is any abnormality that cannot be attributed to Gigabyte/AORUS during the warranty period, it is not covered by the warranty. More info: https://member.aorus.com/global/productwarranty

    2x M.2 SSD slots (Supports 2x PCIe® Gen4x4 NVMe™ M.2 SSD, Up to 4TB)

    *The storage capacity may differ by country and region. Please contact your local dealers or retailers for the latest product information.
    **If there is any abnormality that cannot be attributed to Gigabyte/AORUS during the warranty period, it is not covered by the warranty. More info:https://member.aorus.com/global/productwarranty

    2x M.2 SSD slots (Supports 2x PCIe® Gen4x4 NVMe™ M.2 SSD, Up to 4TB)

    *The storage capacity may differ by country and region. Please contact your local dealers or retailers for the latest product information.
    **If there is any abnormality that cannot be attributed to Gigabyte/AORUS during the warranty period, it is not covered by the warranty. More info:https://member.aorus.com/global/productwarranty

    Keyboard Type
    3-zone RGB Backlit Keyboard, Up to 1.7mm Key-travel (Support N-Key)
    3-zone RGB Backlit Keyboard, Up to 1.7mm Key-travel (Support N-Key)
    1-zone RGB Backlit Keyboard, Up to 1.5mm Key-travel (15 colors, with 10-key)
    1-zone RGB Backlit Keyboard, Up to 1.5mm Key-travel (15 colors, with 10-key)
    I/O Port
    Left Side：

    1 x DC in
    1 x RJ-45
    1 x HDMI 2.1
    1 x Type-A support USB3.2 Gen2
    1 x Type-C with Thunderbolt™4 (support USB4, DisplayPort™ 1.4
    and Power Delivery 3.0)

    Right Side：

    1 x Type-A support USB3.2 Gen2
    1 x Type-C support USB3.2 Gen2, DisplayPort™ 1.4
    1 x MicroSD (UHS-II)
    1 x Audio Jack support mic / headphone combo
    Left Side：

    1 x DC in
    1 x RJ-45
    1 x HDMI 2.1
    1 x Type-A support USB3.2 Gen2
    1 x Type-C with Thunderbolt™4 (support USB4, DisplayPort™ 1.4
    and Power Delivery 3.0)

    Right Side：

    1 x Type-A support USB3.2 Gen2
    1 x Type-C support USB3.2 Gen2, DisplayPort™ 1.4
    1 x MicroSD (UHS-II)
    1 x Audio Jack support mic / headphone combo
    Left Side：

    1 x Type-A support USB3.2 Gen1
    1 x Audio Jack support mic / headphone combo

    Right Side：

    1 x Type-C support USB3.2 Gen2, Power Delivery 3.0
    1 x Type-A support USB3.2 Gen2

    Rear Side：

    1 x Type-C support USB3.2 Gen2, DisplayPort™ 1.4
    1 x DC in
    1 x HDMI 2.1
    1 x RJ-45
    Left Side：

    1 x Type-A support USB3.2 Gen1
    1 x Audio Jack support mic / headphone combo

    Right Side：

    1 x Type-C support USB3.2 Gen2, Power Delivery 3.0
    1 x Type-A support USB3.2 Gen2

    Rear Side：

    1 x Type-C support USB3.2 Gen2, DisplayPort™ 1.4
    1 x DC in
    1 x HDMI 2.1
    1 x RJ-45
    Audio
    2x 2W Speaker
    Microphone
    Dolby Atmos®
    Smart Amp Technology
    2x 2W Speaker
    Microphone
    Dolby Atmos®
    Smart Amp Technology
    2x 2W Speaker
    Microphone
    Dolby Atmos®
    2x 2W Speaker
    Microphone
    Dolby Atmos®
    Communications
    Wi-Fi: Intel® Wi-Fi 7 Wireless (802.11be 2x2)
    LAN: 1G
    Bluetooth: Bluetooth® V5.4
    Wi-Fi: Intel® Wi-Fi 7 Wireless (802.11be 2x2)
    LAN: 1G
    Bluetooth: Bluetooth® V5.4
    Wi-Fi: Intel® Wi-Fi 6E (802.11ax 2x2)
    LAN: 1G
    Bluetooth: Bluetooth® V5.2
    Wi-Fi: Intel® Wi-Fi 6E (802.11ax 2x2)
    LAN: 1G
    Bluetooth: Bluetooth® V5.2
    Webcam
    FHD (1080p) IR Webcam
    Build-in array Microphone
    Support Windows Hello Face Authentication
    FHD (1080p) IR Webcam
    Build-in array Microphone
    Support Windows Hello Face Authentication
    HD (720p) Webcam
    Build-in array Microphone
    HD (720p) Webcam
    Build-in array Microphone
    Security
    Firmware-based TPM, supports Intel® Platform Trust Technology (Intel® PTT)
    Firmware-based TPM, supports Intel® Platform Trust Technology (Intel® PTT)
    Security (Kensington® Type) Lock Slot
    Firmware-based TPM, supports Intel® Platform Trust Technology (Intel® PTT)
    Security (Kensington® Type) Lock Slot
    Firmware-based TPM, supports Intel® Platform Trust Technology (Intel® PTT)
    Battery
    Li Polymer 99Wh
    Li Polymer 99Wh
    Lithium-Ion 73Wh
    Lithium-Ion 73Wh
    Adapter
    240W AC Adapter, 100W PD
    240W AC Adapter, 100W PD
    180W AC Adapter, 100W PD
    180W AC Adapter, 100W PD
    Dimensions (W x D x H)
    35.6(W) x 25.4(D) x 2.0~2.7(H) cm / 14.01(W) x 10(D) x 0.78~1.06(H) inch

    *The dimensions of the laptop may vary according to the configuration, manufacturing process and measurement method, please refer to the actual situation.

    35.6(W) x 25.4(D) x 2.0~2.7(H) cm / 14.01(W) x 10(D) x 0.78~1.06(H) inch

    *The dimensions of the laptop may vary according to the configuration, manufacturing process and measurement method, please refer to the actual situation.

    36.1(W) x 25.9(D) x 2.51~2.89(H) cm / 14.21(W) x 10.19(D) x 0.98~1.13(H) inch​

    *The dimensions of the laptop may vary according to the configuration, manufacturing process and measurement method, please refer to the actual situation.

    36.1(W) x 25.9(D) x 2.51~2.89(H) cm / 14.21(W) x 10.19(D) x 0.98~1.13(H) inch​

    *The dimensions of the laptop may vary according to the configuration, manufacturing process and measurement method, please refer to the actual situation.

    Weight
    ~2.3 kg / ~5.07 lb

    *The weight of the laptop may vary according to the configuration, manufacturing process and measurement method, please refer to the actual situation.

    ~2.3 kg / ~5.07 lb

    *The weight of the laptop may vary according to the configuration, manufacturing process and measurement method, please refer to the actual situation.

    ~2.5 kg / ~5.64 lb

    *The weight of the laptop may vary according to the configuration, manufacturing process and measurement method, please refer to the actual situation.

    ~2.5 kg / ~5.64 lb

    *The weight of the laptop may vary according to the configuration, manufacturing process and measurement method, please refer to the actual situation.

    Color
    Midnight Gray
    Aurora Gray

    *Only available in some specific areas.

    Midnight Gray
    Aurora Gray

    *Only available in some specific areas.

    Gunmetal Gray
    Gunmetal Gray
