    Compare Products

    • CPU
      1. AMD Socket AM5, support for : AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors
      (Please refer "CPU Support List" for more information.)
      1. AMD Socket AM5, support for: AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors
      (Please refer "CPU Support List" for more information.)
      1. AMD Socket AM5, support for: AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors
      (Please refer "CPU Support List" for more information.)
      1. AMD Socket AM5, support for : AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors
      (Please refer "CPU Support List" for more information.)
    • Socket
    • Socket AM5
      Socket AM5
      Socket AM5
      Socket AM5
    • Chipset
      1. AMD X670
      1. AMD X670
      1. AMD X670
      1. AMD X670
    • Memory
      1. Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 MT/s memory modules
      2. 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
      3. Dual channel memory architecture
      4. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
      5. Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory module
      (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)
      1. Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 MT/s memory modules
      2. 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
      3. Dual channel memory architecture
      4. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
      5. Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
      (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)
      1. Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MT/s memory modules
      2. 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
      3. Dual channel memory architecture
      4. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
      5. Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
      (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)
      1. Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 MT/s memory modules
      2. 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
      3. Dual channel memory architecture
      4. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
      5. Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
      (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)
    • Onboard Graphics
    • Integrated Graphics Processor:
      1. 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz
        * Support for DisplayPort 1.4 version and HDR.
      2. 1 x USB Type-C® port, supporting USB 3.2 Gen 2 and DisplayPort video outputs and a maximum resolution of 3840x2160@144 Hz
        * Support for DisplayPort 1.4 version and HDR.
      3. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
        * Support for HDMI 2.1 version and HDCP 2.3.
        ** Support native HDMI 2.1 TMDS compatible ports.
      (Graphics specifications may vary depending on CPU support.)
      Integrated Graphics Processor:
      1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
        * Support for HDMI 2.1 version and HDCP 2.3.
        ** Support native HDMI 2.1 TMDS compatible ports.
      (Graphics specifications may vary depending on CPU support.)
      Integrated Graphics Processor:
      1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
        * Support for HDMI 2.1 version and HDCP 2.3.
        ** Support native HDMI 2.1 TMDS compatible ports.
      (Graphics specifications may vary depending on CPU support.)
      Integrated Graphics Processor:
      1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
        * Support for HDMI 2.1 version and HDCP 2.3.
        ** Support native HDMI 2.1 TMDS compatible ports.
      2. 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz
        * Support for DisplayPort 1.4 version and HDR.
      (Graphics specifications may vary depending on CPU support.)
    • Audio
      1. Realtek® ALC1220-VB CODEC
        * The back panel line out jack supports DSD audio.
      2. Support for DTS:X® Ultra
      3. High Definition Audio
      4. 2/4/5.1/7.1-channel output
        * You can change the functionality of an audio jack using the audio software. To configure
        7.1-channel audio, access the audio software for audio settings.
      5. Support for S/PDIF Out
      1. Realtek® Audio CODEC
      2. High Definition Audio
      3. 2/4/5.1/7.1-channel
        * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
      1. Realtek® Audio CODEC
      2. High Definition Audio
      3. 2/4/5.1/7.1-channel
        * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
      1. Realtek® ALC1220-VB CODEC
        * The front panel line out jack supports DSD audio.
      2. ESS ES9118 DAC chip
      3. Support for DTS:X® Ultra
      4. High Definition Audio
      5. 2/4/5.1-channel
        * You can change the functionality of an audio jack using the audio software. To configure 5.1-channel audio, access the audio software for audio settings.
      6. Support for S/PDIF Out
    • LAN
      1. Intel® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
      1. Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
      1. Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
      1. Marvell® AQtion AQC113C 10GbE LAN chip
        (10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps)
    • Expansion Slots
    • 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 5.0 x16 mode
      2.  AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
      3.  AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
        * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.
      Chipset:
      1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
      2. 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x2 (PCIEX2)
      1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 4.0 x16 mode
      2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
      3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
        * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.
      Chipset:
      1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
      2. 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x2 (PCIEX2)
      1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors Processors support PCIe 4.0 x16 mode
      2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
      3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
        * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.
      Chipset:
      1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
      2. 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x2 (PCIEX2)
      1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 5.0 x16 mode
        * The M2B_CPU and M2C_CPU connectors share bandwidth with the PCIEX16 slot. When the M2B_CPU or M2C_CPU connectors is populated, the PCIEX16 slot operates at up to x8 mode.
      2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
      3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
        (The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.)
      Chipset:
      1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
      2. 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x2 (PCIEX2)
    • Wireless Communication module
    • Intel® Wi-Fi 6E AX210 (PCB rev. 1.0)
      1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
      2. BLUETOOTH 5.3
      3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
      AMD Wi-Fi 6E RZ616 (MT7922A22M) (PCB rev. 1.1)
      1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
      2. BLUETOOTH 5.2
      3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
      (Actual data rate may vary depending on environment and equipment.)
      AMD Wi-Fi 6E RZ616 (MT7922A22M)
      1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
      2. BLUETOOTH 5.2
      3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
      (Actual data rate may vary depending on environment and equipment.)
      AMD Wi-Fi 6E RZ616 (MT7922A22M)
      1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
      2. BLUETOOTH 5.2
      3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
      (Actual data rate may vary depending on environment and equipment.)
      Intel® Wi-Fi 6E AX210 (PCB rev. 1.0)
      1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
      2. BLUETOOTH 5.3
      3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
      AMD Wi-Fi 6E RZ616 (MT7922A22M) (PCB rev. 1.1)
      1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
      2. BLUETOOTH 5.2
      3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
      (Actual data rate may vary depending on environment and equipment.)
    • Storage Interface
    • 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
      1. AMDRyzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 5.0 x4/x2 SSD
      2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSD
      3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSD
      1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 5.0 x4/x2 SSD
      2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSD
      3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSD
      2 x M.2 connectors (M2C_SB, M2D_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD

      6 x SATA 6Gb/s connectors
      * The PCIEX2 slot shares bandwidth with the SATA3 4/5 connectors. The SATA3 4/5 connectors will become unavailable when a device is installed in the PCIEX2 slot.

      RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
      RAID 0, RAID 1, and RAID 10 support for SATA storage devices
      1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 5.0 x4/x2 SSDs
      2. AMD Ryzen™ 8000 Series-Phoenix 1/Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
      1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 4.0 x4/x2 SSDs
      2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
      3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs
      Chipset:
      1. 2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2C_SB, M2D_SB)
      2. 4 x SATA 6Gb/s connectors
      RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
      RAID 0, RAID 1, and RAID 10 support for SATA storage devices
      1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
      1. AMD Ryzen™ Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors Series Processors support PCIe 5.0 x4/x2 SSDs
      2. AMD Ryzen™ 8000 Series-Phoenix 1/Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
      1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 4.0 x4/x2 SSDs
      2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
      3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs
      Chipset:
      1. 2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2C_SB, M2D_SB)
      2. 4 x SATA 6Gb/s connectors
      RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
      RAID 0, RAID 1, and RAID 10 support for SATA storage devices
      1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 5.0 x4/x2 SSDs
      2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
      3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs
      2 x M.2 connectors (M2B_CPU/M2C_CPU), integrated in the CPU, supporting Socket 3,M key, type 22110/2280 SSDs:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 5.0 x4/x2 SSDs
        * The M2B_CPU and M2C_CPU connectors will become unavailable when using the AMD Ryzen™ 8000 Series-Phoenix 1/Phoenix 2 Processors.
      1 x M.2 connector (M2D_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:
      1. AMD Ryzen™ 7000 Series Processors support PCIe 5.0 x4/x2 SSDs
      2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
      3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
      6 x SATA 6Gb/s connectors
      RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
      RAID 0, RAID 1, and RAID 10 support for SATA storage devices
    • USB
    • CPU:
      1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support
      2. 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
      CPU + USB 2.0 Hub:
      1. 2 x USB 2.0/1.1 ports on the back panel
      Chipset:
      1. 2 x USB Type-C® ports, with USB 3.2 Gen 2x2 support (1 port on the back panel, 1 port available through the internal USB header)
      2. 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
      3. 4 x USB 3.2 Gen 1 ports available through the internal USB headers
      4. 4 x USB 2.0/1.1 ports available through the internal USB headers
      Chipset+USB 3.2 Gen 1 Hub:
      1. 4 x USB 3.2 Gen 1 ports on the back panel
      CPU:
      1. 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
      2. 2 x USB 3.2 Gen 1 ports on the back panel
      CPU + USB 2.0 Hub:
      1. 4 x USB 2.0/1.1 ports on the back panel
      Chipset:
      1. 2 x USB Type-C® ports, with USB 3.2 Gen 2x2 support (1 port on the back panel, 1 port available through the internal USB header)
      2. 8 x USB 3.2 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
      3. 4 x USB 2.0/1.1 ports available through the internal USB headers
      CPU:
      1. 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
      2. 2 x USB 3.2 Gen 1 ports on the back panel
      CPU + USB 2.0 Hub:
      1. 4 x USB 2.0/1.1 ports on the back panel
      Chipset:
      1. 2 x USB Type-C® ports, with USB 3.2 Gen 2x2 support (1 port on the back panel, 1 port available through the internal USB header)
      2. 8 x USB 3.2 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
      3. 4 x USB 2.0/1.1 ports available through the internal USB headers
      CPU:
      1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support
      2. 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
      CPU + USB 2.0 Hub:
      1. 4 x USB 2.0/1.1 ports on the back panel
      Chipset:
      1. 2 x USB Type-C® ports, with USB 3.2 Gen 2x2 support (1 port on the back panel, 1 port available through the internal USB header)
      2. 4 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
      3. 4 x USB 3.2 Gen 1 ports available through the internal USB headers
      4. 4 x USB 2.0/1.1 ports available through the internal USB headers
    • Internal I/O Connectors
      1. 1 x 24-pin ATX main power connector
      2. 2 x 8-pin ATX 12V power connectors
      3. 1 x CPU fan header
      4. 1 x water cooling CPU fan header
      5. 4 x system fan headers
      6. 4 x system fan/water cooling pump headers
      7. 2 x addressable LED strip headers
      8. 2 x RGB LED strip headers
      9. 1 x CPU cooler LED strip/RGB LED strip header
      10. 4 x M.2 Socket 3 connectors
      11. 6 x SATA 6Gb/s connectors
      12. 1 x front panel header
      13. 1 x front panel audio header
      14. 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
      15. 2 x USB 3.2 Gen 1 headers
      16. 2 x USB 2.0/1.1 headers
      17. 1 x noise detection header
      18. 1 x THB_U4 add-in card connector
      19. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
      20. 1 x power button
      21. 1 x reset button
      22. 1 x reset jumper
      23. 1 x Clear CMOS jumper
      24. 2 x temperature sensor headers
      25. Voltage Measurement Points
      1. 1 x 24-pin ATX main power connector
      2. 2 x 8-pin ATX 12V power connectors
      3. 1 x CPU fan header
      4. 1 x water cooling CPU fan header
      5. 3 x system fan headers
      6. 1 x CPU cooler LED strip/RGB LED strip header
      7. 2 x addressable LED strip headers
      8. 2 x RGB LED strip headers
      9. 4 x SATA 6Gb/s connectors
      10. 4 x M.2 Socket 3 connectors
      11. 1 x front panel header
      12. 1 x front panel audio header
      13. 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
      14. 2 x USB 3.2 Gen 1 headers
      15. 2 x USB 2.0/1.1 headers
      16. 1 x THB_U4 add-in card connector
      17. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
      18. 1 x power button
      19. 1 x reset button
      20. 1 x Clear CMOS button
      21. 1 x reset jumper
      22. 1 x Clear CMOS jumper
      1. 1 x 24-pin ATX main power connector
      2. 2 x 8-pin ATX 12V power connectors
      3. 1 x CPU fan header
      4. 1 x water cooling CPU fan header
      5. 3 x system fan headers
      6. 1 x CPU cooler LED strip/RGB LED strip header
      7. 2 x addressable LED strip headers
      8. 2 x RGB LED strip headers
      9. 4 x SATA 6Gb/s connectors
      10. 4 x M.2 Socket 3 connectors
      11. 1 x front panel header
      12. 1 x front panel audio header
      13. 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
      14. 2 x USB 3.2 Gen 1 headers
      15. 2 x USB 2.0/1.1 headers
      16. 1 x THB_U4 add-in card connector
      17. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
      18. 1 x power button
      19. 1 x reset button
      20. 1 x Clear CMOS button
      21. 1 x reset jumper
      22. 1 x Clear CMOS jumper
      1. 1 x 24-pin ATX main power connector
      2. 2 x 8-pin ATX 12V power connectors
      3. 1 x CPU fan header
      4. 1 x water cooling CPU fan header
      5. 4 x system fan headers
      6. 4 x system fan/water cooling pump headers
      7. 2 x addressable LED strip headers
      8. 2 x RGB LED strip headers
      9. 1 x CPU cooler LED strip/RGB LED strip header
      10. 4 x M.2 Socket 3 connectors
      11. 6 x SATA 6Gb/s connectors
      12. 1 x front panel header
      13. 1 x front panel audio header
      14. 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
      15. 2 x USB 3.2 Gen 1 headers
      16. 2 x USB 2.0/1.1 headers
      17. 1 x noise detection header
      18. 1 x THB_U4 add-in card connector
      19. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
      20. 1 x power button
      21. 1 x reset button
      22. 2 x temperature sensor headers
      23. 1 x reset jumper
      24. 1 x Clear CMOS jumper
      25. Voltage Measurement Points
    • Back Panel Connectors
      1. 1 x Q-Flash Plus button
      2. 2 x SMA antenna connectors (2T2R)
      3. 1 x DisplayPort
      4. 1 x HDMI port
      5. 1 x USB Type-C® port (DisplayPort), with USB 3.2 Gen 2 support
      6. 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
      7. 4 x USB 3.2 Gen 2 Type-A ports (red)
      8. 4 x USB 3.2 Gen 1 ports
      9. 2 x USB 2.0/1.1 ports
      10. 1 x RJ-45 port
      11. 1 x optical S/PDIF Out connector
      12. 2 x audio jacks
      1. 1 x Q-Flash Plus button
      2. 2 x SMA antenna connectors (2T2R)
      3. 1 x HDMI port
      4. 6 x USB 3.2 Gen 1 ports
      5. 4 x USB 2.0/1.1 ports
      6. 2 x USB 3.2 Gen 2 Type-A ports (red)
      7. 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
      8. 1 x RJ-45 port
      9. 3 x audio jacks
      1. 1 x Q-Flash Plus button
      2. 2 x SMA antenna connectors (2T2R)
      3. 1 x HDMI port
      4. 6 x USB 3.2 Gen 1 ports
      5. 4 x USB 2.0/1.1 ports
      6. 2 x USB 3.2 Gen 2 Type-A ports (red)
      7. 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
      8. 1 x RJ-45 port
      9. 3 x audio jacks
      1. 1 x Q-Flash Plus button
      2. 1 x Clear CMOS button
      3. 2 x SMA antenna connectors (2T2R)
      4. 1 x DisplayPort
      5. 1 x HDMI port
      6. 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
      7. 1 x USB Type-C® port, with USB 3.2 Gen 2 support
      8. 6 x USB 3.2 Gen 2 Type-A ports (red)
      9. 4 x USB 2.0/1.1 ports
      10. 1 x RJ-45 port
      11. 1 x optical S/PDIF Out connector
      12. 2 x audio jacks
    • Operating System
      1. Support for Windows 11 64-bit
      2. Support for Windows 10 64-bit
      1. Support for Windows 11 64-bit
      2. Support for Windows 10 64-bit
      1. Support for Windows 11 64-bit
      2. Support for Windows 10 64-bit
      1. Support for Windows 11 64-bit
      2. Support for Windows 10 64-bit
    • Form Factor
      1. E-ATX Form Factor; 30.5cm x 26.9cm
      1. ATX Form Factor; 30.5cm x 24.4cm
      1. ATX Form Factor; 30.5cm x 24.4cm
      1. E-ATX Form Factor; 30.5cm x 26.9cm
